D-Link DWL-6600AP Administrator's Guide

Unied Access Point Administrator’s Guide
Unied Access Point Administrator’s Guide
Page 21
January 2015
Section 2 - Getting Started
Conguring Security on the Wireless Access Point
You congure secure wireless client access by conguring security for each virtual access point (VAP) that you
enable. You can congure up to 16 VAPs per radio that simulate multiple APs in one physical access point. By default,
only one VAP is enabled. For each VAP, you can congure a unique security mode to control wireless client access.
Each radio has 16 VAPs, with VAP IDs from 0-15. By default, only VAP 0 on each radio is enabled. VAP0 has the
following default settings:
•) VLAN ID: 1
•) Broadcast SSID: Enabled
•) SSID: dlink1
•) Security: None
•) MAC Authentication Type: None
•) Redirect Mode: None
All other VAPs are disabled by default. The default SSID for VAPs 1–15 is ”dlinkx” where x is the VAP ID.
To prevent unauthorized access to the UAP, we recommend that you select and congure a security option other than
None for the default VAP and for each VAP that you enable.
For information about how to congure the security settings on each VAP, see “Virtual Access Point Settings” on page
47.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
