DWM- 312
10
ENGLISH
Powering the Router
The router features a exible power input ranging from 5 volts/2
amps to 18 volts/0.7 amps. A minimum of 10 watts total power
is recommended.
Using the Included AC Adapter
1. Attach the barrel connector of included AC adapter to the
DWM-312 power port on the front panel.
2. Attach the AC adapter to an appropriate AC socket.
Connecting Devices
After the DWM-312 has been successfully installed, the router
can be connected to the end device via the following connection
method:
Over Ethernet
The Ethernet port can be connected to an end device. Use a
standard Category 5/5e/6 RJ-45 Ethernet cable to connect the
end device to the router. The port will auto-negotiate to the
highest possible port speed based on the connected device.
Note that the DWM-312 supports a maximum transfer speed of
100 Mbps over Ethernet.
