D-Link DWR-953V2 User Manual

DWR-953V2
1
ENGLISH
LTE CaT4 Wi-Fi aC1200 RouTER
DWR-953V2
If any of these items are missing from your packaging, contact your
reseller.
12 V 1 a PoWER aDaPTER
CaT5 ETHERNET CaBLE
• A broadband Internet connection
• Computer with:
• Microsoft Windows
®
10/8/7/Vista/XP SP3, or Mac with OS X 10.5 or later
• 500 MHz processor or above and at least 128 MB RAM
• Internet Explorer
®
10, Firefox
®
36, Chrome™ 40, Safari 8 or later with Java installed and
enabled
PaCKaGE CoNTENTS
SYSTEM REQuiREMENTS

D-Link DWR-953V2 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
WAN connection type	RJ-45
4G standard	LTE-TDD & LTE-FDD
3G standards	UMTS
4G LTE category	8
Dual SIM support	No
4G bands supported	700, 800, 900, 1800, 2100, 2300, 2600 MHz
GSM bands supported	850, 900, 1800, 1900 MHz
UMTS bands supported	900, 2100 MHz
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1200 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	866 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	3
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, WAN
Antennas quantity	2
Certification	CE , FCC , PTCRB, EMC , RoHS
Power source type	DC
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	32 mm
Width	154 mm
Height	122 mm
Weight	275 g
