D-Link G416

35D-Link G416 User Manual
Section 3 - Conguration
Advanced Settings... - Dynamic IP
Address Mode Select Static IP if the following information has been provided
by your ISP: IP address, MTU, and DNS server addresses. In most
cases, select Dynamic IP.
IP Address When Static IP is selected as the address mode, the column
for IP address will appear. Enter the IP address provided by
your ISP.
Service Name Enter the ISP service name (optional)
Primary DNS Server Enter the primary DNS server IP address assigned by your ISP.
Secondary DNS Server Enter the secondary DNS server IP address assigned by your
ISP.
MTU Maximum Transmission Unit (1280~1500)- you may need to
change the MTU for optimal performance with your ISP. The
default is 1500.
MAC Address Clone The default MAC address is set to the Internet port’s physical
interface MAC address on the router. You can replace the
Internet port’s MAC address with the MAC address of a
connected client.
