D-Link GO-SW-8G User Manual

D-Link GO-SW-5G/8G 5/8-port Gigabit Easy Desktop Switch
4
LED Indicators
The LED indicators of the Switch include Power, Link/Act and Speed. The following shows the LED indicators for the
Switch along with an explanation of each indicator.
Figure 1-2. LED Indicators
Comprehensive LED indicators display the conditions of the Switch and status of the network. A description of these
LED indicators follows (see LED Indicators). The LED indicators of the Switch include Power and Link/Act , as
described below.
For GO-SW-5G:
 Power Indicator
This green indicator light is on when the Switch is receiving power; otherwise, it is off.
 Link/Act
This LED indicator light is green when the port is connected to a device.The green indicator blinks as data is
transmitted or received.
For GO-SW-8G:
 Power Indicator
This green indicator light is on when the Switch is receiving power; otherwise, it is off.
 Link/Act
This LED indicator light is green when the port is connected to a device.The green indicator blinks as data is
transmitted or received.

D-Link GO-SW-8G Specifications

General

MAC address table	8000 entries
Jumbo frames support	Yes
Packet buffer memory	0.125 MB
Maximum data transfer rate	1 Gbit/s
Supported data transfer rates	10, 20, 100, 200, 1000, 2000 Mbps
10G support	-
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Switch type	Unmanaged
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports quantity	8
Power consumption (typical)	3.9 W
Certification	FCC, ICES, CE, C-tick, VCCI, cUL/UL, CCC, LVD
Product color	White
Mean time between failures (MTBF)	412433 h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Connectivity technology	Wired

Weight and Dimensions

Depth	68.5 mm
Width	128 mm
Height	25.4 mm
Weight	195 g
