D-Link GO-SW-8G User Manual

D-Link GO-SW-5G/8G 5/8-port Gigabit Easy Desktop Switch
10
Appendix A
Technical Specifications
General
Standards:
IEEE 802.3ab 1000BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3 10BASE-T
IEEE 802.3x Flow Control
IEEE 802.3az Energy-Efficient Ethernet (EEE)
Protocol:
CSMA/CD
Data Transfer
Rate:
10Mbps (Half-duplex) Ethernet:
20Mbps (Full-duplex)
100Mbps (Half-duplex) Fast Ethernet:
200Mbps (Full-duplex)
Gigabit Ethernet: 2000Mbps (Full-duplex)
Topology:
Star
Network Cables:
Ethernet: 2-pair UTP Cat. 3,4,5, Unshield Twisted Pair (UTP) Cable
Fast Ethernet: 2-pair UTP Cat. 5, Unshield Twisted Pair (UTP) Cable
Gigabit Ethernet: 4-pair UTP Cat. 5, Unshield Twisted Pair (UTP) Cable
Number of Ports:
Five/Eight 10/100/1000BASE-T Gigabit Ethernet ports
Physical and Environmental
DC Inputs:
AC-DC 5V/1A
Operating
Temperature:
0 °C ~ 40℃(32°F ~ 104F °)
Storage
Temperature:
-10°C ~ 70°C (14°F ~ 158°F)
Humidity:
5% ~ 95% RH, non-condensing
Dimensions:
GO-SW-5G :97 x 79 x 25 mm
GO-SW-8G: 128 x 68.5 x 25.4 mm
EMI
CE Class B
Safety:
LVD

D-Link GO-SW-8G Specifications

General

MAC address table	8000 entries
Jumbo frames support	Yes
Packet buffer memory	0.125 MB
Maximum data transfer rate	1 Gbit/s
Supported data transfer rates	10, 20, 100, 200, 1000, 2000 Mbps
10G support	-
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Switch type	Unmanaged
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports quantity	8
Power consumption (typical)	3.9 W
Certification	FCC, ICES, CE, C-tick, VCCI, cUL/UL, CCC, LVD
Product color	White
Mean time between failures (MTBF)	412433 h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Connectivity technology	Wired

Weight and Dimensions

Depth	68.5 mm
Width	128 mm
Height	25.4 mm
Weight	195 g
