To make it possible to connect to this server from the Internet using the FTP ALG, the FTP ALG and rules should
be configured as follows:
Web Interface
A. Define the ALG:
1. Go to Objects > ALG > Add > FTP ALG
2. Enter Name: ftp-inbound
3. Check Allow client to use active mode
4. Uncheck Allow server to use passive mode
5. Click OK
B. Define the Service:
1. Go to Objects > Services > Add > TCP/UDP Service
2. Enter the following:
• Name: ftp-inbound
• Type: select TCP from the list
• Destination: 21 (the port the FTP server resides on)
• ALG: select the "ftp-inbound" that has been created
3. Click OK
C. Define a rule to allow connections to the public IP on port 21 and forward that to the internal FTP server:
1. Go to Rules > IP Rules > Add > IPRule
2. Now enter:
6.2.3. The FTP ALG Chapter 6. Security Mechanisms
214
