D-Link DNS-343 User Manual
7
Hardware Overview
Front View
COMPONENT DESCRIPTION
OLED Screen This screen displays detailed information about the following:
System Information
HD Status
Server Status
Power Button Use this button to switch the device on or off.
To switch on the device press the button once.
To switch off the device hold the button down for 5 seconds.
Next Button Use this button to display the System Information (system state), HD Status (hard drive state) and Server Status (server
status state) on the OLED.
Press the button once to alternate between the different Status screens.
Power Button Next Button
OLED Screen
