D-Link Wireless N Router DIR-615 User Manual

40D-Link DIR-615 User Manual
Section 3 - Configuration
The Ping Test is used to send Ping packets to test if a
computer is on the Internet. Enter the IP Address that you
wish to Ping, and click Ping.
The results of your ping attempts will be displayed here.
System Check
Ping Test:
Ping Results:

D-Link Wireless N Router DIR-615 Specifications

General

Frequency Band	2.4 GHz
LAN Ports	4 x 10/100Mbps
WAN Ports	1 x 10/100Mbps
Wireless Speed	Up to 300 Mbps
Antenna Gain	5 dBi
Firewall	NAT, SPI
Humidity	10% to 90% non-condensing
Wireless Standard	IEEE 802.11n
Antenna Type	2 x External Antennas
Security	WEP, WPA, WPA2, WPS
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 65 °C
