D-Link Wireless N Router DIR-615 User Manual

60D-Link DIR-615 User Manual
Section 5 - Connecting to a Wireless Network
3. The Wireless Network Connection box will appear. Enter the
WPA-PSK passphrase and click Connect.
It may take 20-30 seconds to connect to the wireless network. If the
connection fails, please verify that the WPA-PSK settings are correct.
The WPA-PSK passphrase must be exactly the same as on the
wireless router.

D-Link Wireless N Router DIR-615 Specifications

General

Frequency Band	2.4 GHz
LAN Ports	4 x 10/100Mbps
WAN Ports	1 x 10/100Mbps
Wireless Speed	Up to 300 Mbps
Antenna Gain	5 dBi
Firewall	NAT, SPI
Humidity	10% to 90% non-condensing
Wireless Standard	IEEE 802.11n
Antenna Type	2 x External Antennas
Security	WEP, WPA, WPA2, WPS
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 65 °C
