25.2 Unpacking and Assembly
1. Open the top of the Box. Once open, place two hands on each side of the device and pull
the 1 Series, including the foam packers on each end, out of the box. Remove the foam
packers
Note: Be sure to remove all of the accessories, such as the manual, calibration output
certificate, power cord and eyewear before discarding the box.
2. Plug the “D” shape male fixture into the corresponding receptacle on the lower left-hand
side of the device. Plug the unit into any grounded, three prong, electrical outlet. The unit
is now ready for use. To remove the power cord simply grasp the “D” shaped plug and
remove it from the 1 Series “D” shaped power inlet.
25.3 How to Position the Patient
25.3.1 Hand and Foot Treatments:
Position the device on a flat surface with the lamps facing up. Place the patient’s hands or feet
directly on top of the plastic lamp guard. For best results you should position the patient’s hands,
or feet, as close as possible to the center of the fixture.
Note: When treating your hands and feet, be careful to not place too much weight or pressure on
the acrylic surface. Excess pressure can cause the acrylic surface to crack and break.
25.3.2 Larger Area Treatment:
Position the 1 Series so that the lamps are perpendicular to the surface on which the device is
standing on. Position the part of the patient’s body that you wish to treat nine (9) inches away
from the lamps.
