Table 32: Factory settings
Default settings
M/M M/T T/T
Installation
note
Identifier Description Value
LA Language ITA ITA ITA
SP Setpoint pressure [bar] 3,0 3,0 3,0
P1 Setpoint P1 [bar] 2,0 2,0 2,0
P2 Setpoint P2 [bar] 2,5 2,5 2,5
P3 Setpoint P3 [bar] 3,5 3,5 3,5
FP Test frequency in manual mode 40,0 40,0 40,0
RC Rated current of electric pump [A 0,0 0,0 0,0
RT Direction of rotation 0 (UVW) 0 (UVW) 0 (UVW)
FN Rated frequency [Hz] 50,0 50,0 50,0
OD Type of system 1 ( Rigid ) 1 ( Rigid ) 1 ( Rigid )
RP Pressure drop for restart [bar] 0,5 0,5 0,5
AD Address 0 (Auto) 0 (Auto) 0 (Auto)
PR Pressure sensor remote 0 (Absent) 0 (Absent) 0 (Absent)
MS Measurement system
0
(International )
0
(International )
0
(Internazional)
SX Maximum setpoint [bar] 9
9 for size
4.7A
13 for size
10.5A
13
TB Delay for water failure block [s] 10 10 10
T1 Shutdown delay [s] 2 2 2
T2 Shutdown delay [s] 10 10 10
GP Proportional gain coefficient 0,6 0,6 0,6
GI Integral gain coefficient 1,2 1,2 1,2
FS Maximum rotation frequency [Hz] 50,0 50,0 50,0
FL Minimum rotation frequency [Hz] 0,0 0,0 0,0
NA Active inverters N N N
NC Simultaneous inverters NA NA NA
IC Reserve configuration 1 (Auto) 1 (Auto) 1 (Auto)
ET Exchange time [h] 2 2 2
CF Carrier [kHz] 20 10 5
AC Acceleration 5 5 4
AY Anti cycling 0 ( Disabled ) 0 ( Disabled ) 0 ( Disabled )
AE Anti-blocking function 1( enabled ) 1( enabled ) 1( enabled )
I1 Function I1 1 (float ) 1 (float ) 1 (float )
I2 Function I2 3 (P Aux) 3 (P Aux) 3 (P Aux)
I3 Function I3 5 (Disabled) 5 (Disabled) 5 (Disabled)
O1 Output 1 function 2 2 2
O2 Output 2 function 2 2 2
SF Starting frequency [Hz] FN FN FN
ST Starting time [s] 1 1 1
PW Password settings 0 0 0
