DAB e.sybox mini3 User Manual
4
of 1
of 1 rating
75 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
EN
ENGLISH
53
Reduced menu (visible)
Extended menu (direct access or password)
Main Menu
User Menu
mode
Monitor Menu
set-minus
Setpoint Menu
mode-set
Manual Menu
set-minus-plus
Installer Menu
mode-set-minus
T
ech.
Assist. Menu
mode-set-plus
MAIN
(Main Page)
ST
A
TUS
RS
Revs per minute
VP
Pressure
VF
Display of ow
PO
Power absorbed by
pump
C1
Pump phase current
SV
Supply voltage
SR
Supply range
TE
Dissipator
temperature
PKm
Pressure measured at
intake
CT
Contrast
SP
Setpoint pressure
ST
A
TUS
RI
Speed setting
VP
Pressure
VF
Display of ow
PO
Power absorbed by
pump
C1
Pump phase current
RS
Revs per minute
TE
Dissipator
temperature
SV
Supply voltage
SR
Supply range
RP
Decrease pressure
for restart
TB
Block time for
water lack.
Menu Selection
BK
Back lighting
OD
T
ype of
plant
T2
Delay in switching off
TK
Backlighting switch-
on time
MS
Measuring system
GP
Proportional gain.
LA
Language
AS
Wireless Devices
GI
Integral gain
TE
Dissipator temperature
EK
Enabling
low pressure function
on suction
RM
Maximum speed
PK
Low pressure threshold
on suction
AY
Anti Cycling
T1
Low pr
. delay
AE
Anti-blocking
Hours switched on
Working hours
Number of starts
AF
AntiFreeze
17
19
Table of Contents
English
3
Default Chapter
3
Table of Contents
3
Key
6
Warnings
6
Responsibility
7
Description of the Integrated Inverter
8
Integrated Expansion Vessel
8
Technical Characteristics
9
1 General
7
2 Installation
10
Vertical Configuration
10
Hydraulic Connections
11
Loading Operation Installation above Head and below Head
11
Horizontal Configuration
12
Hydraulic Connections
12
Orientation of the Interface Panel
12
Loading Operation Installation above Head and below Head
13
3 Commissioning
14
Electrical Connections
14
Configuration of the Integrated Inverter
15
Priming
15
4 The Keypad and the Display
16
Direct Access with a Combination of Keys
17
Access by Name with a Drop-Down Menu
20
Structure of the Menu
20
Blocking Parameter Setting by Password
21
Enabling and Disabling the Motor
21
5 Meaning of the Individual Parameters
22
User Menu
22
Status
22
RS: Rotation Speed Display
22
VP: Pressure Display
22
VF: Flow Display
22
PO: Absorbed Power Display
22
C1: Phase Current Display
22
SV: Supply Voltage
22
SR: Supply Range
22
Output Flow Meter
23
VE: Version Display
23
FF: Fault Log Display
23
Monitor Menu
23
CT: Display Contrast
23
BK: Display Brightness
23
TK: Backlight Switch-On Time
23
LA: Language
23
TE: Dissipator Temperature Display
23
Setpoint Menu
23
SP: Setting the Setpoint Pressure
24
Manual Menu
24
Status
24
RI: Speed Setting
24
VP: Pressure Display
24
VF: Flow Display
24
PO: Absorbed Power Display
24
C1: Phase Current Display
24
RS: Rotation Speed Display
24
SV: Tupply Voltage
25
SR: Supply Range
25
TE: Dissipator Temperature Display
25
Installer Menu
25
RP: Setting the Pressure Fall to Restart
25
OD: Type of Plant
25
MS: Measuring System
25
AS: Association of Devices
26
EK: Setting the Low Pressure Function on Suction
26
PK: Low Pressure Threshold on Suction
26
T1: Low Pressure Delay (Function Detecting Low Pressure on Suction)
26
Technical Assistance Menu
27
TB: Water Lack Blockage Time
27
T2: Delay in Switching off
27
GP: Proportional Gain Coefficient
27
GI: Integral Gain Coefficient
27
RM: Maximum Speed
27
AY: Anti Cycling
27
AE: Enabling the Anti-Block Function
27
AF: Enabling the Anti-Freeze Function
27
Setting Low Pressure Detection on Suction
27
RF: Fault and Warning Reset
28
PW: Change Password
28
6 Protection Systems
28
Anti-Cycling (Protection against Continuous Cycles Without Utility Request)
29
Anti-Freeze (Protection against Freezing of Water in the System)
29
BL" Anti Dry-Run (Protection against Dry Running)
29
Description of Blockages
29
BP1" Blockage Due to Fault of the Delivery Pressure Sensor
30
BP2" Blockage Due to Fault of the Suction Pressure Sensor
30
PB" Blockage Due to Supply Voltage Outside Specifications
30
SC" Blockage Due to Short Circuit between the Motor Phases
30
Manual Reset of Error Conditions
30
Self-Reset of Error Conditions
30
7 Reset and Factory Settings
31
General System Reset
31
Factory Settings
31
Restoring the Factory Settings
31
8 Particular Installations
32
Inhibiting Self-Priming
32
Wall Installation
33
9 Maintenance
33
Accessory Tool
33
Emptying the System
33
Non-Return Valve
34
Motor Shaft
34
Expansion Vessel
35
10 Troubleshooting
35
11 Updating the Firmware
37
12 Disposal
37
13 Guarantee
37
Français
38
Légende
41
Avertissements
41
Responsabilité
42
1 Généralités
42
Description de L'inverseur Intégré
43
Vase D'expansion Intégré
43
Caractéristiques Techniques
44
2 Installation
45
Configuration Verticale
46
Raccords Hydrauliques
46
Opérations de Chargement - Installation Battant Supérieur Et Battant Inférieur
47
Configuration Horizontale
47
Raccords Hydrauliques
48
Orientation du Tableau D'interface
48
3 Mise en Fonction
49
Branchements Électriques
49
Configuration de L'inverseur Intégré
50
Amorçage
51
4 Le Clavier Et L'écran
52
Accès Direct Avec Combinaisons de Touches
53
Accès Par Nom À L'aide du Menu Déroulant
56
Structure des Pages de Menu
56
Blocage Paramètres Par Mot de Passe
57
Habilitation Et Désactivation du Moteur
57
Menu Utilisateur
58
État
58
RS: Affiche L'état de la Pompe
58
VP: Affichage de la Pression
58
VF: Affichage du Flux
58
PO : Affichage de la Puissance Distribuée
58
C1: Affichage du Courant de Phase
58
SV: Tension D'alimentation
58
SR: Plage D'alimentation
58
Débit
59
VE: Affichage de la Version
59
FF: Affichage Pannes Et Avertissements (Historique)
59
5 Signification des Paramètres
58
Menu de Paramétrage
59
SP: Réglage de la Pression de Paramétrage
60
Menu Écran
59
CT: Contraste Écran
59
BK : Luminosité Écran
59
TK: Temps D'allumage Éclairage de Fond
59
LA: Langue
59
TE: Affichage de la Température du Dissipateur
59
Menu Manuel
60
État
60
RI: Paramétrage Vitesse
60
Vp:affichage de la Pression
60
VF: Affichage du Flux
60
PO : Affichage de la Puissance Distribuée
60
C1: Affichage du Courant de Phase
60
RS: Affichage de la Vitesse de Rotation
60
SV: Tension D'alimentation
61
SR: Plage D'alimentation
61
TE: Affichage de la Température du Dissipateur
61
Menu Installateur
61
RP: Paramétrage de la Diminution de Pression Pour Redémarrage
61
OD: Type D'installation
61
MS: Système de Mesurage
61
AS: Association de Dispositifs
62
EK: Réglage Fonction Basse Pression en Aspiration
62
PK: Seuil Basse Pression en Aspiration
62
T1: Temporisation Basse Pression (Fonction de Relevage Basse Pression en Aspiration)
63
Menu Assistance Technique
63
TB: Temps de Blocage Manque D'eau
63
T2: Temporisation de L'arrêt
63
GP: Coefficient de Gain Proportionnel
63
GI: Coefficient de Gain Intégral
63
RM: Vitesse Maximum
63
AY: Anti Cycling
63
AE: Habilitation de la Fonction D'anti-Blocage
63
AF: Habilitation de la Fonction D'antigel
64
Réglage du Relevage de Basse Pression en Aspiration
64
RF: Remise À Zéro des Pannes Et Avertissements
64
PW: Modifiés Password
64
6 Systèmes de Protection
64
Description des Blocages
65
