DIGITAL INDICATOR
DN500N
22
PRINT DELAY TIME
F48
00
0.0
∫
9.9
Set print delay time from 0.1 to 9.9 sec
0.0 sec: No use for print delay time
SET KEY TARE OPERATION
● 0 Key Tare No Use
F52
1 Key Tare Use Available
FUNCTION AUTO SETTING
F77
This is to automatically set the setting value of Function to the initial factory default..
** If other setting value is applied, please do not access to F77 Mode.
SET NEAR ZERO(EMPTY) RANGE
F80
0.10
This is near Zero range to check the emptiness of scale.
EX) 000: Weight display is “0”: Near Zero Relay is operated.
010: Weight display is below 10”: Near Zero Relay is operated.
150: Weight display is below “150”: Near Zero Relay is operated.
SET ZERO DISPLAY RANGE
F81
XXXXXX
This is to set the zero display range.
EX) If 50 is set, the numbers less than 50 will be all displayed
as “0.”
CHECK CALIBRATION SPAN CONSTANT
F89
On SET-UP Mode, KEY 89 and then “CLEAR” KEY is pressed, SPAN constant will be
displayed on weight section. Once you check the SPAN constant, please return to
previous menu by pressing “CLEAR" Key. If you change SPAN constant, please press
“ENTER" Key and then”CLEAR" Key.
*Note: Please do not change constant at random since a tolerance can be caused between
the actual weight values.
※ REFERENCE
If there is a mall tolerance on weight value. You can adjust it by changing SPAN constant.
EX) Actual weight value: 100Kg. Indicator display value: 105Kg, F89 Constant 1.23456
How to change = (Actual weight value ÷ Indicator display value) X F89 Constant =
(100÷105) X 1.23456 = 1.17577)
Once you change the current F89 constant 1.23456 to 1.17577, the indicator display value will
be shown as 100Kg.
