dacell DN500N - Page 30

DIGITAL INDICATOR
DN500N
29
▶ COMMAND MODE
( READ COMMAND )
TO → INDICATOR COMMAND DESCRIPTION INDICATOR RESPONSE
STX ID. NO. RTIM BCC ETX
Command to transmit Time
data of indicator
Transmit Time DATA(6)
- STX ID.NO. RTIM 000000 BCC ETX
STX ID. NO. RDAT BCC ETX
Command to transmit Date
data of indicator
Transmit Date DATA(8)
- STX ID. NO. RDAT 00000000 BCC ETX
STX ID. NO. RSNO BCC ETX
Command to transmit Serial
Number
Transmit S/N (6)
- STX ID. NO. RSNO 000000 BCC ETX
STX ID. NO. RCNO BCC ETX
Command to transmit Code
Number
Transmit Code Number(6)
- STX ID. NO. RCNO 000000 BCC ETX
STX ID. NO. RPNO BCC ETX
Command to transmit Part
Number
Transmit P/N(2)
- STX ID. NO. RPNO 00 BCC ETX
STX ID. NO. RTAR BCC ETX
Command to transmit “KEY
Tare” Weight
Transmit KEY Tare (6)
- STX ID. NO. RTAR 000000 BCC ETX
STX ID. NO. RCWT BCC ETX
Command to transmit
“Current weight”
Transmit currently measured weight
- STX ID. NO. RCWT DATA1 BCC ETX
STX ID. NO. RSUB BCC ETX
Command to transmit
“Subtotal”
- STX ID. NO. RSUB P/N(2) CODE_BUF(6)
COUNT(6) S.T.W(8)
UNIT
BCC ETX
No decimal point.
STX ID. NO. RGRD BCC ETX
Command to transmit
“Total”
- STX ID.NO. RGRD P/N(2) CODE(6)
G.T.W(8)
UNIT BCC ETX
No decimal point
STX ID. NO. RFIN BCC ETX
Command to transmit
measuring status
Transmit measuring status (FN: finished,
RN: under measuring)
- STX ID. NO. RFIN FN (Measuring
completion 6 digit weight)
BCC ETX
- STX ID. NO. RFIN RN BCC ETX
STX ID. NO. RCWD BCC ETX
Command to transmit all the
current data memorized in
the indicator
Transmit “Current weight”
- STX ID. NO. RCWD DATA2 BCC ETX
※ DATA1 (14)
※ DATA2 (52)
Current weight END
HEADER1 (2) HEADER2 (2)
Weight including sign, decimal point (14)
UNIT (kg or t)(2)
DATE (8) TIME (6) P/N (2)
CODE
(6)
S/N (6) TARE (6) NET.W (8) GROSS.W (8) UNIT (2)
