dacell DN500N - Page 31

DIGITAL INDICATOR
DN500N
30
▶ COMMAND MODE
( WRITE COMMAND)
TO → INDICATOR COMMAND DESCRIPTION INDICATOR RESPONSE
STX ID. NO. WTAR BCC ETX Command to set “TARE”
STX ID. NO. WTAR ACK BCC ETX
or
STX ID. NO. WTAR NAK BCC ETX
STX ID. NO. WTRS BCC ETX Command “TARE RESET”
STX ID. NO. WTRS ACK BCC ETX
or
STX ID. NO. WTRS NAK BCC ETX
STX ID. NO. WZER BCC ETX “Command to set “ZERO”
STX ID. NO. WZER ACK BCC ETX
or
STX ID. NO. WZER NAK BCC ETX
STX ID. NO. WPRT BCC ETX
Command to carry out
“PRINT”
STX ID. NO. WPRT ACK BCC ETX
or
STX ID. NO. WPRT NAK BCC ETX
STX ID. NO. WSPR BCC ETX
Command to carry out
“SUB-PRINT”
STX ID. NO. WSPR ACK BCC ETX
or
STX ID. NO. WSPR NAK BCC ETX
STX ID. NO. WGPR BCC ETX
Command to carry out
“GRAND-PRINT”
STX ID. NO. WGPR ACK BCC ETX
or
STX ID. NO. WGPR NAK BCC ETX
STX ID. NO. WDAT DATE BCC ETX
ex) STX ID.NO WDAT 00000000 BCC ETX
Command to change the date
on Timer memorized in
indicator.
STX ID. NO. WDAT ACK BCC ETX
or
STX ID. NO. WDAT NAK BCC ETX
STX ID. NO. WTIM TIME BCC ETX
ex) STX ID.NO WTIM 000000 BCC ETX
Command to change the time
on Timer memorized in
indicator.
STX ID. NO. WTIM WCK BCC ETX
or
STX ID. NO. WTIM NAK BCC ETX
STX ID. NO. WSNO S/N(6) BCC ETX
ex) STX ID.NO WSNO 000000 BCC ETX
Command to change
“Serial” memorized
inside.
STX ID. NO. WSNO ACK BCC ETX
or
STX ID. NO. WSNO NAK BCC ETX
STX ID. NO. WPNO P/N(2) BCC ETX
ex) STX ID.NO WPNO 00 BCC ETX
Command to change “PART
NUMBER” to the DATA that is
now being transmitted.
STX ID. NO. WPNO ACK BCC ETX
or
STX ID. NO. WPNO NAK BCC ETX
STX ID. NO. WCNO C/N(6) BCC ETX
ex) STX ID.NO WCNO 000000 BCC ETX
Command to change “CODE”
to the DATA that is now being
transmitted.
STX ID. NO. WCNO ACK BCC ETX
or
STX ID. NO. WCNO NAK BCC ETX
