Dishwasher Service Manual
Troubleshooting and Repair
82
13. Membrane
To change the membrane, rst separate the inner and outer door assemblies.
• Remove the #15 torx head screws around the perimeter of the inner door panel.
• Remove the screws mounted horizontally into the hinge arms.
• Carefully separate the two pieces, being cautious of sharp edges, to expose the
membrane inside of the door assembly.
• There are four Phillips head mounting screws mounted vertically up under the membrane
which can be accessed from the inside of the door.
13a
13b
13c
