Dishwasher Service Manual
Troubleshooting and Repair
81
Door Components
12. Separating the Door
To separate the inner and outer door assemblies:
• R
emove the # 15 torx head screws around the perimeter of the inner door panel.
• Remove the 4 screws mounted horizontally into the raised portion of the inner door liner.
• Carefully separate the two pieces, being cautious of sharp edges, to expose the
serviceable parts inside of the door assembly.
12a
12b
