Dacor Dishwasher - Upper Rack Removal; Rack Slide Removal

Dishwasher Service Manual
Troubleshooting and Repair
87
19. Upper Rack Removal
To remove the upper rack:
• Pull the rack all the way out of the unit. Lifting on both sides at the same time, until the
rack snaps into a locked position.
• Locate the four locking tabs at each corner. With a pocket screwdriver, depress the tab
towards the center of the rack, and pull up on the rack until it clears the tab.
• Repeat this at all four corners until the rack assembly is free from the locks.
• Lift the assembly straight up and remove from the unit.
20. Rack Slide Removal
• The Rack Slides are secured to the unit with nuts (2 per side) accessible inside
right and left side beneath the rails.
19a
20a
