Dishwasher Service Manual
Troubleshooting and Repair
84
15. Control Board Removal
The control panel is accessed by separating the inner and outer door assemblies.
• Remove the two screws holding the control board access panel to the top rail of the
outer door.
• Turn the access panel over exposing the board, and release the four stand-offs which are
securing the board to the access panel.
• Carefully disconnect ribbon cable from control board.
Beware of sharp edges on panel opening from ribbon cable
15a
15b
To Next Page
