Dacor Dishwasher - Detergent Cup Removal; Anti-Siphon Valve Removal

Dishwasher Service Manual
Troubleshooting and Repair
88
21. Detergent Cup Removal
To remove the detergent cup:
• Gain access to the inside of the door by separating the inner and outer door assemblies.
• Remove the six phillips head screws holding the inner portion of the detergent cup assembly
to the outer portion.
• Disconnect the wires attached the unit and remove both pieces from the door
22. Anti-Siphon Valve Removal
• Pull unit from cabinet.
• The Anti-Siphon valve is secured to the tank by a round plastic nut on the inside of the
tank cavity.
• Remove the nut by turning counterclockwise until it is free from the valve.
• The valve can now be removed from the left hand side of the DW.
21a
22a 22b
