Dishwasher Service Manual
Troubleshooting and Repair
72
3. Circulation Pump Removal
• The circulation pump can be removed two ways:
• From the front as a part of the complete circ-sump assembly.
• From the rear after the DW is pulled from the cabinet, and the back panel removed.
• Disconnect hoses and wiring from pump assembly.
• Slide assembly to the left releasing the mounting dampers from the bracket and pull
assembly straight back out of DW for service.
3a
