1. GENERAL INFORMATION
1.1 INTRODUCTION
This Workshop Manual has been written to provide
assistance in the service and overhaul of DAEDONG
1100 series 4 cylinder engines. It should be used in
conjunction with normal workshop practise and infor-
mation contained in current service bulletins. Mention
of certain accepted practices therefore, has been pur-
posely omitted in order to avoid repetition. For overhaul
procedures, the aspantion is made that the engine is
removed from the application.
The engine conforms with USA (EPA/CARB) stage 2
and EEC stage 2 emission legislation.
Most of the general information which is included in the
relevant User's Manual has not been repeated in this
workshop manual and the two publications should be
used together.
Where the information applies only to certain engine
types, this is indicated in the text.
The details of some operations will be different accord-
ing to the type of fuel injection pump which is fi tted.
The specific pump type used can be found by refer-
ence to the manufacturer's identification plate on the
pump body but, generally, the type of pump fitted is
shown below:
Delphi - DP210 Series
Bosch - VP 30
Bosch - EPVE
When reference is made to the "left" or "right" side of
the engine, this is as seen from the fl ywheel end of the
engine.
•
•
•
POWERPART recommended consumable products are
listed under "POWERPART recommended consumable
products". Reference to the relevant consumable prod-
ucts is also made at the beginning of each operation.
Data and dimensions are included in "2.2 Engine Spec-
ifi cation and Data".
Read and remember "1.3 Safety precautions". They
are given for your protection and must be used at all
times.
Danger is indicated in the text by three methods:
