The engine is started pressing this button
when pressed in a state where the main
switch key is placed to an ON position and
the brake lever is pulled.
<TURNING ON HEADLIGHT>
Put main switch key in “ON” position and
turn on headlight switch.
<HEADLIGHT HIGH/LOW BEAM SWITCH>
High beam or low beam can be operated
by the use of high/low beam switch.
HIGH BEAM
...... used when needing extra
light.
LOW BEAM
...... used when other vehicles are
present, in the city, etc.
12
STARTER BUTTON
HEADLIGHT
CAUTION
●The engine will not start if the
brake lever is not pulled.
●Do not hold the brake lever and
pull the throttle grip when the
engine was started. It may damage
the engine.
(HI)
D
(LO)
D
STARTER BUTTON
HEADLIGHT SWITCH
HEADLIGHT HIGH/LOW
BEAM SWITCH
SWITCH POSITION FUNCTION
Headlight, taillight,
position lamp and
meter lights on.
Position lamp, taillight,
and meter lights on.
Light turned off.
(OFF)
(P)
(H)
**E-5 OWNERS(1~47) 02.11.5 4:2 PM 페이지12
