<AIR PRESSURE CHECK>
Check for an appropriate level of air
pressure by examining how the tire sits on
the ground. If you notice any abnormalities
in the shape of the tire with regard to the
area contacting the ground, use a tire
gauge to check tire pressure and adjust the
tire pressure to the appropriate level.
<TIRE PRESSURE>
<CRACKS/DAMAGE>
Check tire tread and sides for cracks and
damage.
<ABNORMAL WEAR>
Check tire tread for signs of abnormal
wear.
<FOREIGN MATERIALS>
Check tire tread and sides for nails, rocks,
etc. That might have become wedged in
the tire.
<TREAD DEPTH>
Check the wear indicator (wear limit
marking) to see if there is an insufficient
amount of tread remaining.
If the indicators are visible, replace tire
with a new one.
27
TIRE INSPECTION
SIZE
AIR PRESSURE
(kgf/)
1 PERSON
RIDING
FRONT
1.75
130/90-10 61J
130/90-10 61J
2.00
1.75
2.00
REAR
REAR
FRONT
FRONT
REAR
2 PERSON
RIDING
CRACKS
NAIL
WEDGED
DAMAGE
ABNORMAL
WEAR
WEAR INDICATOR
LOCATION MARKING
WEAR INDICATOR
(WEAR LIMIT MARKING)
