41
(1) Separate the front cover and front
under cover.
(2) Remove the radiator cap.
(3) Loosen the drain bolt of water pump,
and drain the cooling water.
(4) Tilt the vehicle right hand to drain the
remaining water.
(5) Drain the cooling water in reservoir.
(6) Install the drain bolt.
COOLING WATER CAPACITY:
1400±20CC
CHANGING COOLING WATER CAPACITY:
1000±20CC
RESERVOIR TANK CAPACITY:
400±20CC
(7) Refill the cooling water to radiator.
(8) Start the engine, release the air in the
water, and check the water level.
(9) Install the radiator cap.
(10) Refill the reservoir with cooling water
to upper limit.
Recommended antifreeze: LG-Caltex oil
CX/AF antifreeze EQUM 40%
If electrode is stained or clearance is not
right, satisfactory spark is not produced.
Clean and make adjustment.
Remove the spark plug cap.
Clean around the plug.
Using a plug wrench, remove the plug.
CHANGING COOLING WATER SPARK PLUG
SPARK PLUG
SPARK PLUG CAP
CAUTION
While the engine is hot, don’t open
the radiator cap, because the hot
water burst to cause injury. Stop the
engine and wait until cool down.
Ask change the cooling water for
specialized technician.
DRAIN BOLT
RESERVE TANK
RADIATOR
WATER PUMP
