DAEWOO ELECTRONICS DWF-7570DP - Page 37

3 7
REF No. PARTS CODE PARTS NAME DESCRIPTION Q'TY REMARK
T1 7122401611
SCREW TAPPING T2S TRS 4 x 16 MFZN 4
T2 4507D83030 COVER OUTER TUB PP 1
T3 4505E32030
SCREW PULSATOR FIX 6 x 26.5 1
T4 4505E32050
RING 0 D5.5 1
T5 36 - 1 9700800 PULSATOR PP 1
T6
4509G83080 I NSERT PULSATOR SMS 1025 1
T7 4507D83080 SPECIAL NUT ZNDC2 Cu, Ni COATING 1
T8 45091_83070 SPECIAL WASHER SUS 304 2.OT P144 1
T9 3610085500 ASS'Y FILTER P.P+NYLON 74x130 1
T10 3619800200 ASS'Y SUSPENSION DWF-6670D L=75mm 3
T11 3619800300 ASS'Y SUSPENSION B DWF-6670D, L=80mm 1
T12 3610018100 TUB ASS'Y PP BIO-CERAMIC 1
T13 4507DO5025 FLANGE TUB ADC10
1
T14 3610032200 ASS'Y VALVE DRAIN DWF-5230PN 1
T15 4507D83012 TUB OUTER PP 1
T16 4509M34010 BASE SBHG2 2.OT 1
T17 4505E83100 FIXTURE 6.5 x 23 15
T18 7640801611 BOLT HEX 613-1 8 x 16 SW MFZN 4
T19 3611502800 CUSHION DOWN POM H=18mm 2
T20 SEE NOTE 4 MOTR CONDENSER 1
T21 3611502000 CUSHION UPPER POM 2
T24 7650804211 SPECIAL BOLT 613-1-8x42 MFZN 2
T25 SEE NOTE 9 PULLEY MOTOR 1
T26 7391600011 NUT HEX 6N-1-6 MFZN 1
T27 3616000701 SPECIAL BOLT-PULLEY 6B-1 6 x 20 SM20CK (Zn) 1
T28 3616100600 BALANCER WEIGHT FC20, 3550GR 1
T32 7650802511 SPECIAL BOLT 6B-1-8x25 MFZN 2
T33 3618300100 PLATE GEAR PROTECT SBHG1 1.6T 1
T34 450OD83100 NOZZLE AS BUBBLING 1
T35 4500DO8180 CLAMP SWC
1
T36 4500DO8170 HOSE I D =8.0 OD =12.0 1
T37 4500DO8190 PIPE JOINT ABS
1
T38 SEE NOTE 8 MOTOR SYNCRONOUS
1
T39 3617300601 GEAR MECHANISM GM-8030D
1
T40 7640801611 BOLT HEX 6B-1-8x16 SW MFZN
4
T41 4505E79040 CLAMP HOSE JSW, D2.6 2N8-C
1
T42 4509M79010 HOSE DRAIN PE-1_D
1
T43 45091_79021 CUFF DRAIN HOSE PP
1
(MODEL WITH DRAIN PUMP)
T44 DRAIN PUMP 1
T45 3611200100 CLAMP
SW 2.6D ZN8-C 1
T46 3613207100 HOSE A NBR 1
T47 3611200200
CLAMP B SW 2.6D ZN8-C 1
T48 3613203100 HOSE AS DWF-5230PN
1
