AUTOMATIC WATER SUPPLY SYSTEM FOR BLANKET WASH
The water level would be lowered because the blanket absorbs water at the beginning of washing. There-
fore, after 30 seconds, the operation is interrupted to check the water level, and then the Water is supplied
again until the selected water level is reached.
WATER CURRENTS FOR STRONG WASH
I
t
washes cleanly the heavily stained clothes such as working-clothes, climbing-clothes and blue-jean by
using this strong water currents as shown below.
WATER CURRENTS
PULSATOR SYSTEM
When the new shaped pulsator is rotated C.W or C.C.W at a high speed, it makes the 'heart-shaped' water
currents as shown below.
WATER CURRENTS
A
Water is pushed up near
the tub wall by rotation
Rotate
)~( ~(
f
he pul
o t
sator.
u
~~f
B
Water is pulled down in
the middle of the tub by
rotation of the pulsator.
C
Water currents is generated
by rotation of the pulsator.
SIGNAL
C.C. W
OF
MOTOR
C.W
TIME (SEC.)
.
8
.
5
.
8
.
5
.
8
.
5
.
8
.
5
.
8
.
5
.
8
.
5
.
8
.
5
.
8
.
5
3.2I
.
8
3.2
.
8
C
•
1
CYCLE
