PARTS LIST
36
REF No. PARTS CODE
PARTS NAME DESCRIPTION Q'TY REMARK
P1 3614501800 PLATE TOP ABS 1
P2 3614201400 PANEL FRONT ABS 1
P3 3614201500 PANNEL REAR ABS 1
P4 3611701300 DOOR B ABS 1
P5 3611403100 COVER DOOR ABS
1
P6 3615500500 WINDOW DISPLAY
ABS 1
P7 SEE NOTE 1 ASS'Y P.C.B
1
P8 SEE NOTE 11 TRANS POWER
1
THERMAL FUSE
P9 SEE NOTE 3 HARNESS AS
1
P10 SEE NOTE 7 PUMP BUBBLE
1
P11 3615100200 SPRING DOOR SUS304 D = 2.0
1
P12 3616600600 BUTTON START
SILICON 1
_
P13 3612300100 GASKET SILICON 2
P14 3_6 _10902000 CAP VALVE
ABS 2
P15 SEE NOTE 2
SWITCH POWER 1
P16 SEE NOTE 6 VALVE INLET (WARM)
1
P17
_SEE NOTE 5 VALVE INLET (COLD)
1
P18 3610400500 BODY INLET
FRPP 1
P19 3619003300 SWITCH SAFETY AS DC 15V 10MA
1
P20 3611601910 DECORATOR PC FILM 0.254T
1
P21 3610901000 CAP CR
2
P22 3611504100 CUSHION DOOR CR
4
P23 3619000700 WATER LEVEL SWITCH KANBAYASHI (PS-D6)
1
P24 3611701200 DOOR A
ABS 1
P25 3616001200 SCREW SPECIAL TRS 5 x 75 MFZN
2
P26 7122401211 SCREW TAPPING T2S TRS 4 x 20 MFZN 2
P27 7122402011 SCREW TAPPING
T2S TRS 4 x 12 MFZN 1
B1 3610032600
CONDENSER AS 13.5wF+60iH 1
B2 3612200100 FRAME TOP PP
1
B3 3610801800 CABINET
PCM 0.7T DWF-6670D 1
B4 3610300900 BASE UNDER
PP 1
B5 3611404400 COVER BACK PP
1
B6 3617700400 LEG FIX
RUBBER BUTYL 2
B7 4509M10032 FIXTURE
PP 2
B8
7122502011
SCREW TAPPING
T2S TRS 5 x 20 MFZN 2
B9 3612000200
FIXTURE LEG PPG 2
B10 3618900700 UNIT LEG
RUBBER+BOLT INSERT 2
B11
3613000600 HOLDER LEG
ABS 2
B12 3610901700
CAP LEG L ABS 1
B13 3610901800 CAP LEG R ABS 1
B14 3614506200
PLATE UPPER PP 1
B15 3614502000 PLATE LOWER PP ~1
