EXPLODED VIEW AND PARTS LIST
No. Parts Name Parts Code Description
Q'ty
218M
1 WINDOW DOOR A 9CD16145A0 ACRYL 1
2 WINDOW DOOR B 9CD16145B0 ACRYL 1
3 SPRING DOOR EJECT 9CD3004500 PW-1 2
4 DOOR CASS A 9CD18098A0 MIPS 1
5 DOOR CASS B 9CD18098B0 MIPS 1
6 SPRING C HOLDER 9713008900 STS (T=0.2) 4
7 WINDOW FLT 9CD1614600 ACRYL 1
8 DOOR CD 9CD1809900 MIPS 1
9 BADGE DAEWOO 9CD1500900 ABS 1
10 PLATE EON 9CD0910100 PV SHEET 1
11 PANEL FRONT 9CD0306600 MIPS 1
12 SHAFT WASHER 9CD3601600 ACETAL 1
13 KNOB VOLUME 9CD1336300 ABS 1
14 CUSHION FOOT 9CD4207700 URETHAN FOAM RUBBER 2
15 SHAFT VR 9CD3601500 ACETAL 1
16 DAMPER ASSY 9CD2602800 2
17 BRKT SIDE 9CD2412900 ABS 1
18 KNOB FUNCTION 9CD1336200 ACRYL 1
19 KNOB CONTROL 9CD1336100 ABS 1
20 GUIDE FLT 9CD2505600 ABS 1
21 HEAT SINK 9CD4402800 BSP 1
22 CD MECHANISM 9CD6006900 1
23 COVER TOP 9CD0409600 MIPS 1
24 COVER SIDE L 9CD0409900 MIPS 1
25 COVER SIDE R 9CD0401000 MIPS 1
26 CHASSIS BOTTOM 9CD0607500 MIPS 1
26-1 CHASSIS BOTTOM 9CD0607100 SECC ---
27 HEAT SINK1 9CD4404500 AL ---
27-1 HEAT SINK05 9CD4405100 AL 1
27-2 HEAT SINK2 9CD4405000 AL ---
28 RUBBER SILICON 9CD4207900 RUBBER 1
29 BRKT HEAT TR 9CD2413900 STS 1
30 COVER BACK 9CD0409801 MIPS 1
31 KNOB DECK A 9CD1332900 ABS 1
32 KNOB DECK B 9CD1333000 ABS 1
33 DECK MECHANISM 9CD6006200 1
S1 SCREW TT2 BIN 2.6X10 11
S2 SCREW TT2 BIN 3X10 32
S3 WASHER SCREW 1
S4 SCREW TT2 BIN 3X12 BK 5
S5 SCREW TT2 BIN 4X6 -
S5-1 SCREW TT2 BIN 4X10 4
W1 WASHER PLAIN 1
P1 PCB FRONT 1
P2 PCB MAIN 1
P3 PCB POWER 1
No. Parts Name Parts Code Description
Q'ty
218M
- 6 -
