Electrical Parts List
1 PCB FRONT AS 11000 9CDC056138 AMI-218MV 59 WIRE JUMPER JW706 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO
2 PCB FRONT B001 9CD6581400 247X139X1.6T 60 WIRE JUMPER JW707 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
3 C CERA CC701 CCXF1H223Z 50V F 0.022MF Z (TAPPING) 61 WIRE JUMPER JW708 W581GY6095 AWG22 1/0.65 SN 6 AUTO
4 C CERA CC703~706 CCXF1H223Z 50V F 0.022MF Z (TAPPING) 62 WIRE JUMPER JW709 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
5 C CERA CC710 CCXF1H223Z 50V F 0.022MF Z (TAPPING) 63 WIRE JUMPER JW710 W581GY1005 AWG22 1/0.65 SN 10 AUTO
6 C CERA CC711 CXCH1H150J 50V CH 15PF J (TAPPING) 64 WIRE JUMPER JW711 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
7 C CERA CC712 CXCH1H180J 50V CH 18PF J (TAPPING) 65 WIRE JUMPER JW712 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
8 C CERA CC713~714 CXCH1H330J 50V CH 33PF J (TAPPING) 66 WIRE JUMPER JW713 W581GY1005 AWG22 1/0.65 SN 10 AUTO
9 C CERA CC715 CCXF1H223Z 50V F 0.022MF Z (TAPPING) 67 WIRE JUMPER JW714~715 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
10 C CERA CC719 CCXF1H223Z 50V F 0.022MF Z (TAPPING) 68 WIRE JUMPER JW716 W581GY6095 AWG22 1/0.65 SN 6 AUTO
11 C CERA CC722 CCXF1H104Z 50V F 0.1MF Z 69 WIRE JUMPER JW717~718 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
12 C CERA CC726 CXCH1H331J 50V CH 330PF J (TAPPING) 70 WIRE JUMPER JW719 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO
13 C CERA CC728~729 CCXF1H103Z 50V F 0.01MF Z (TAPPING) 71 WIRE JUMPER JW720~721 W581GY1005 AWG22 1/0.65 SN 10 AUTO
14 C CERA CC730 CXCH1H820J 50V CH 82PF J (TAPPING) 72 WIRE JUMPER JW722 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
15 C CERA CC731 CXCH1H470J 50V CH 47PF J (TAPPING) 73 WIRE JUMPER JW723~727 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
16 C ELECTRO CE702 CEXF1H229V 50V RSS 2.2MF (5X11) TP 74 WIRE JUMPER JW728~729 W581GY1505 AWG22 1/0.65 GY 15 AUTO
17 C ELECTRO CE704 CEXF1A102V 10V RSS 1000MF (10X16) TP 75 WIRE JUMPER JW730~731 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
18 C ELECTRO CE705 CEXF1E101V 25V RSS 100MF (6.3X11) TP 76 WIRE JUMPER JW732~733 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
19 C ELECTRO CE706 CEXF1H229V 50V RSS 2.2MF (5X11) TP 77 WIRE JUMPER JW735 W581GY6095 AWG22 1/0.65 SN 6 AUTO
20 C ELECTRO CE708 CEXF1H100V 50V RSS 10MF (5X11) TP 78 WIRE JUMPER JW736~737 W581GY1005 AWG22 1/0.65 SN 10 AUTO
21 C ELECTRO CE709 CEXF1H339V 50V RSS 3.3MF (5X11) TP 79 WIRE JUMPER JW738 W581GY1505 AWG22 1/0.65 GY 15 AUTO
22 C ELECTRO CE710 CEXF1E470V 25V RSS 47MF (5X11) TP 80 WIRE JUMPER JW739~740 W581GY6095 AWG22 1/0.65 SN 6 AUTO
23 C ELECTRO CE711 CEXF1H229V 50V RSS 2.2MF (5X11) TP 81 WIRE JUMPER JW741~742 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
24 CONN AS CN705 9728802700 #26 13P FLAT 220MM P=2.5 82 WIRE JUMPER JW743 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
25 CONN AS CN708 9728802800 #26 3P FLAT 360MM P=2.5 83 WIRE JUMPER JW744~745 W581GY1005 AWG22 1/0.65 SN 10 AUTO
26 CONN AS CN709 9728802900 #26 3P FLAT 100MM P=2.0 84 WIRE JUMPER JW746 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO
27 CONN WAFER CW401 9736407700 52084-1310 13P BOTTOM 85 WIRE JUMPER JW747~749 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
28 CONN WAFER CW402 9736407900 52084-1010 10P BOTTOM 86 WIRE JUMPER JW750~751 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO
29 DIODE D704 DZN4148--- 1N4148 AUTO 52MM 87 WIRE JUMPER JW752~754 W581GY6095 AWG22 1/0.65 SN 6 AUTO
30 DIODE D706~707 DZN4148--- 1N4148 AUTO 52MM 88 WIRE JUMPER JW755~756 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
31 DIODE D713 DZN4148--- 1N4148 AUTO 52MM 89 WIRE JUMPER JW757 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
32 VFD FD701 DSVA09MM10SVA09MM10 90 WIRE JUMPER JW758 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
33 IC IC701 138199316N U-COM M38199-316N 91 WIRE JUMPER JW759 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
34 IC IC702 1M24C04--- M24C04-BN6 92 WIRE JUMPER JW760 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
35 IC PRE AMP IC705 1TM97CT38P LTM97CT-38P 93 WIRE JUMPER JW761~762 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
36 IC IC706 1TDA7479D- TDA7479D 94 WIRE JUMPER JW763 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
37 WIRE JUMPER JW301~304 W581GY1505 AWG22 1/0.65 GY 15 AUTO 95 WIRE JUMPER JW764~765 W581GY6095 AWG22 1/0.65 SN 6 AUTO
38 WIRE JUMPER JW305~306 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO 96 WIRE JUMPER JW766 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
39 WIRE JUMPER JW307~308 W581GY1005 AWG22 1/0.65 SN 10 AUTO 97 WIRE JUMPER JW767 W581GY6095 AWG22 1/0.65 SN 6 AUTO
40 WIRE JUMPER JW309~310 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO 98 WIRE JUMPER L701 W581GY6095 AWG22 1/0.65 SN 6 AUTO
41 WIRE JUMPER JW311~313 W581GY6095 AWG22 1/0.65 SN 6 AUTO 99 LED LD713~714 DLTL307EE- LTL-307EE(RED)PI5
42 WIRE JUMPER JW314~315 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO 100 TR Q701 TKRC107M-- KRC107-M TAPPING(KSR1006)
43 WIRE JUMPER JW316~322 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO 101 TR Q711 TKRC107M-- KRC107-M TAPPING(KSR1006)
44 WIRE JUMPER JW322 W581GY6095 AWG22 1/0.65 SN 6 AUTO 102 R CARBON FILM R351 RD-AZ101J- 1/6 100 OHM J
45 WIRE JUMPER JW323~328 W581GY1005 AWG22 1/0.65 SN 10 AUTO 103 R CARBON FILM R352 RD-AZ331J- 1/6 330 OHM J
46 WIRE JUMPER JW329 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO 104 R CARBON FILM R354 RD-AZ271J- 1/6 270 OHM J
47 WIRE JUMPER JW330 W581GY1505 AWG22 1/0.65 GY 15 AUTO 105 R CARBON FILM R355 RD-AZ331J- 1/6 330 OHM J
48 WIRE JUMPER JW331 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO 106 R CARBON FILM R356 RD-AZ391J- 1/6 390 OHM J
49 WIRE JUMPER JW333 W581GY6095 AWG22 1/0.65 SN 6 AUTO 107 R CARBON FILM R357 RD-AZ471J- 1/6 470 OHM J
50 WIRE JUMPER JW334 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO 108 R CARBON FILM R358 RD-AZ561J- 1/6 560 OHM J
51 WIRE JUMPER JW335 W581GY6095 AWG22 1/0.65 SN 6 AUTO 109 R CARBON FILM R360 RD-AZ101J- 1/6 100 OHM J
52 WIRE JUMPER JW336 W581GY1505 AWG22 1/0.65 GY 15 AUTO 110 R CARBON FILM R361 RD-AZ151J- 1/6 150 OHM J
53 WIRE JUMPER JW337 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO 111 R CARBON FILM R362 RD-AZ181J- 1/6 180 OHM J
54 WIRE JUMPER JW338~341 W581GY1505 AWG22 1/0.65 GY 15 AUTO 112 R CARBON FILM R363 RD-AZ271J- 1/6 270 OHM J
55 WIRE JUMPER JW342 W581GY6095 AWG22 1/0.65 SN 6 AUTO 113 R CARBON FILM R364 RD-AZ331J- 1/6 330 OHM J
56 DIODE JW700 DZN4148--- 1N4148 AUTO 52MM 114 R CARBON FILM R365 RD-AZ391J- 1/6 390 OHM J
57 WIRE JUMPER JW701~702 W581GY1005 AWG22 1/0.65 SN 10 AUTO 115 R CARBON FILM R366 RD-AZ471J- 1/6 470 OHM J
58 WIRE JUMPER JW703~705 W581GY6095 AWG22 1/0.65 SN 6 AUTO 116 R CARBON FILM R367 RD-AZ561J- 1/6 560 OHM J
LOCATIO
PART-CODE PART-DESC REMARKSPART-DESC REMARKS NO PART-NAMENO PART-NAME LOCATION PART-CODE
- 16 -
