Daewoo AMI-V225M - Page 20

Electrical Parts List
LOCATIO
N
PART-CODE PART-DESC REMARKSPART-DESC REMARKS NO PART-NAMENO PART-NAME LOCATION PART-CODE
117 R CARBON FILM R368 RD-AZ821J- 1/6 820 OHM J 27 C CERA CC401~402 CXCH1H101J 50V CH 100PF J (TAPPING)
118 R CARBON FILM R369 RD-AZ101J- 1/6 100 OHM J 28 C CERA CC404 CCXF1H223Z 50V F 0.022MF Z (TAPPING)
119 R CARBON FILM R370 RD-AZ151J- 1/6 150 OHM J 29 C CERA CC405~406 CXCH1H101J 50V CH 100PF J (TAPPING)
120 R CARBON FILM R371 RD-AZ821J- 1/6 820 OHM J 30 C CERA CC408~409 CCXF1H223Z 50V F 0.022MF Z (TAPPING)
121 R CARBON FILM R701~702 RD-AZ103J- 1/6 10K OHM J 31 C CERA CC410 CCXF1H104Z 50V F 0.1MF Z
122 R CARBON FILM R707 RD-AZ103J- 1/6 10K OHM J 32 C CERA CC501 CCXF1H223Z 50V F 0.022MF Z (TAPPING)
123 R CARBON FILM R710 RD-AZ470J- 1/6 47 OHM J 33 C CERA CC502 CCXB1H102K 50V B 1000PF K (TAPPING)
124 R CARBON FILM R711~712 RD-AZ103J- 1/6 10K OHM J 34 C CERA CC503 CCXF1H223Z 50V F 0.022MF Z (TAPPING)
125 R CARBON FILM R719~721 RD-AZ152J- 1/6 1.5K OHM J 35 C CERA CC504 CCXB1H472K 50V B 4700PF K (TAPPING)
126 R CARBON FILM R722 RD-AZ472J- 1/6 4.7K OHM J 36 C CERA CC505 CCXF1H103Z 50V F 0.01MF Z (TAPPING)
127 R CARBON FILM R724 RD-AZ223J- 1/6 22K OHM J 37 C CERA CC506 CCXB1H152K 50V B 1500PF K (TAPPING)
128 R CARBON FILM R748 RD-AZ181J- 1/6 180 OHM J 38 C CERA CC507 CCXF1H103Z 50V F 0.01MF Z (TAPPING)
129 R CARBON FILM R751 RD-AZ152J- 1/6 1.5K OHM J 39 C CERA CC508~509 CCXF1H104Z 50V F 0.1MF Z
130 R CARBON FILM R759 RD-AZ106J- 1/6 10M OHM J 40 C CERA CC510 CCXF1H333Z 50V F 0.033MF Z (TAPPING)
131 R CARBON FILM R760 RD-AZ334J- 1/6 330K OHM J 41 C CERA CC511 CCXB1H151K 50V B 150PF K (TAPPING)
132 R CARBON FILM R761 RD-AZ101J- 1/6 100 OHM J 42 C CERA CC512~513 CCXF1H104Z 50V F 0.1MF Z
133 R CARBON FILM R762 RD-AZ100J- 1/6 10 OHM J 43 C CERA CC514 CCXF1H103Z 50V F 0.01MF Z (TAPPING)
134 R CARBON FILM R773 RD-AZ103J- 1/6 10K OHM J 44 C CERA CC515 CCXB1H152K 50V B 1500PF K (TAPPING)
135 R CARBON FILM R775 RD-AZ103J- 1/6 10K OHM J 45 C CERA CC516 CCXB1H222K 50V B 2200PF K (TAPPING)
136 R CARBON FILM R776 RD-AZ334J- 1/6 330K OHM J 46 C CERA CC517 CCXF1H153Z 50V F 0.015MF Z
137 R CARBON FILM R777~778 RD-AZ104J- 1/6 100K OHM J 47 C CERA CC518 CCXF1H104Z 50V F 0.1MF Z
138 R CARBON FILM R779 RD-AZ334J- 1/6 330K OHM J 48 C CERA CC519 CCXB1H331K 50V B 330PF K (TAPPING)
139 R CARBON FILM R780 RD-AZ561J- 1/6 560 OHM J 49 C CERA CC520 CCXF1H103Z 50V F 0.01MF Z (TAPPING)
140 R CARBON FILM R781 RD-AZ473J- 1/6 47K OHM J 50 C CERA CC521~522 CCXB1H472K 50V B 4700PF K (TAPPING)
141 R CARBON FILM R782 RD-AZ472J- 1/6 4.7K OHM J 51 C CERA CC523 CCXF1H333Z 50V F 0.033MF Z (TAPPING)
142 R CARBON FILM R783 RD-AZ223J- 1/6 22K OHM J 52 C CERA CC524 CCXB1H331K 50V B 330PF K (TAPPING)
143 R CARBON FILM R784 RD-AZ683J- 1/6 68K OHM J 53 C CERA CC525 CCXF1H104Z 50V F 0.1MF Z
144 R CARBON FILM R785 RD-AZ182J- 1/6 1.8K OHM J 54 C CERA CC526 CCXB1H151K 50V B 150PF K (TAPPING)
145 SW TACT SW701~703 5S50101001 KPT-1105A 1C-1P 55 C CERA CC527 CCXB1H391K 50V B 390PF K (TAPPING)
146 SW TACT SW705~709 5S50101001 KPT-1105A 1C-1P 56 C CERA CC528 CCXB1H152K 50V B 1500PF K (TAPPING)
147 SW TACT SW711~722 5S50101001 KPT-1105A 1C-1P 57 C CERA CC529 CCXF1H104Z 50V F 0.1MF Z
148 SW TACT SW726 5S50101001 KPT-1105A 1C-1P 58 C CERA CC530 CCXF1H103Z 50V F 0.01MF Z (TAPPING)
1 PCB MAIN AS 10000 9CDC054910 AMI-208MV 59 C CERA CC531 CCXF1H223Z 50V F 0.022MF Z (TAPPING)
2 PCB MAIN B001 9CD6581900 330X197X1.6T 60 C CERA CC532~533 CCXF1H104Z 50V F 0.1MF Z
3 C CERA CC001 CCZB1E102K 25V B 1000PF K (AXIAL) 61 C CERA CC534 CCXF1H333Z 50V F 0.033MF Z (TAPPING)
4 C CERA CC002 CCXF1H103Z 50V F 0.01MF Z (TAPPING) 62 C CERA CC535 CCXF1H103Z 50V F 0.01MF Z (TAPPING)
5 C CERA CC004 CCXF1H103Z 50V F 0.01MF Z (TAPPING) 63 C CERA CC536 CCXF1H104Z 50V F 0.1MF Z
6 C CERA CC006 CCXF1H103Z 50V F 0.01MF Z (TAPPING) 64 C CERA CC538 CCXF1H473Z 50V F 0.047MF Z (TAPPING)
7 C CERA CC102 CCXF1H103Z 50V F 0.01MF Z (TAPPING) 65 C CERA CC539 CCXF1H103Z 50V F 0.01MF Z (TAPPING)
8 C CERA CC103 CCXF1H104Z 50V F 0.1MF Z 66 C CERA CC540~541 CXCH1H330J 50V CH 33PF J (TAPPING)
9 C CERA CC104 CZCH1E120J CH 25V 12PF J 67 C CERA CC542 CXCH1H100D 50V CH 10PF D (TAPPING)
10 C CERA CC105 CZCH1E820J CH 25V 82PF J AXL 52MM 68 C CERA CC543 CCXF1H223Z 50V F 0.022MF Z (TAPPING)
11 C CERA CC201~202 CCXF1H473Z 50V F 0.047MF Z (TAPPING) 69 C CERA CC544 CCXF1H104Z 50V F 0.1MF Z
12 C CERA CC203 CCZB1E561K 25V B 560PF K (AXIAL) 70 C CERA CC545 CXCH1H309C 50V CH 3PF C
13 C CERA CC205 CCZB1E472K 25V B 4700PF K (AXIAL) 71 C CERA CC547~549 CCXF1H223Z 50V F 0.022MF Z (TAPPING)
14 C CERA CC206 CCXF1H473Z 50V F 0.047MF Z (TAPPING) 72 C CERA CC550~551 CCXF1H103Z 50V F 0.01MF Z (TAPPING)
15 C CERA CC207 CCXF1H104Z 50V F 0.1MF Z 73 C CERA CC553 CCXF1H223Z 50V F 0.022MF Z (TAPPING)
16 C CERA CC209 CCXF1H473Z 50V F 0.047MF Z (TAPPING) 74 C CERA CC554~555 CCXF1H104Z 50V F 0.1MF Z
17 C CERA CC210~213 CCXF1H103Z 50V F 0.01MF Z (TAPPING) 75 C CERA CC558~560 CCXF1H104Z 50V F 0.1MF Z
18 C CERA CC216~217 CCZB1E682K 25V B 6800PF K (AXIAL) 76 C CERA CC601~602 CCXB1H821K 50V B 820PF K (TAPPING)
19 C CERA CC251 CCXF1H104Z 50V F 0.1MF Z 77 C CERA CC605 CCXB1H331K 50V B 330PF K (TAPPING)
20 C CERA CC252 CCXF1H103Z 50V F 0.01MF Z (TAPPING) 78 C CERA CC607 CCXB1H102K 50V B 1000PF K (TAPPING)
21 C CERA CC253~254 CCZB1E102K 25V B 1000PF K (AXIAL) 79 C CERA CC611~614 CCXB1H391K 50V B 390PF K (TAPPING)
22 C CERA CC255 CZCH1E360J CH 25V 36PF J AXIAL 52MM 80 C CERA CC615 CCXF1H104Z 50V F 0.1MF Z
23 C CERA CC256 CZCH1E330J CH 25V 33PF J AXIAL 52MM 81 C CERA CC617~618 CCXB1H471K 50V B 470PF K (TAPPING)
24 C CERA CC257 CCXF1H103Z 50V F 0.01MF Z (TAPPING) 82 C CERA CC620~621 CCXB1H821K 50V B 820PF K (TAPPING)
25 C CERA CC258 CCZB1E102K 25V B 1000PF K (AXIAL) 83 C MYLAR CC622~623 CMXM1H122J 50V 0.0012MF J
26 C CERA CC290 CCXF1H104Z 50V F 0.1MF Z 84 C CERA CC624~625 CCXB1H681K 50V B 680PF K (TAPPING)
