Electrical Parts List
LOCATIO
PART-CODE PART-DESC REMARKSPART-DESC REMARKS NO PART-NAMENO PART-NAME LOCATION PART-CODE
85 C CERA CC801~802 CCXB1H102K 50V B 1000PF K (TAPPING) 143 C ELECTRO CE806 CEXF1E470V 25V RSS 47MF (5X11) TP
86 C CERA CC803~804 CCXF1H103Z 50V F 0.01MF Z (TAPPING) 144 C ELECTRO CE901~902 CEYF1E222V 25V RSS 2200MF (16X25)
87 C CERA CC806~808 CCXF1H103Z 50V F 0.01MF Z (TAPPING) 145 C ELECTRO CE903 CEXF1E222V 25V RSS 2200MF (16X25) TP
88 C CERA CC809~810 CCXF1H223Z 50V F 0.022MF Z (TAPPING) 146 C ELECTRO CE904~907 CEXF1H229V 50V RSS 2.2MF (5X11) TP
89 C CERA CC911~915 CCXF1H223Z 50V F 0.022MF Z (TAPPING) 147 C ELECTRO CE911~914 CEXF1H470V 50V RSS 47MF (6.3X11) TP
90 C ELECTRO CE001 CEXF1E470V 25V RSS 47MF (5X11) TP 148 FILTER CERA CF001 5PE107MS3A SFE107MS3-A
91 C ELECTRO CE101 CEXF1H229V 50V RSS 2.2MF (5X11) TP 149 FILTER CERA CF002 5PE107MJA- SFE 10.7MHZ RED
92 C ELECTRO CE102 CEXF1E221V 25V RSS 220MF (8X11.5) TP 150 FILTER CF201 5PPCFAZ077 PCFAZ077
93 C ELECTRO CE201 CEXF1H220V 50V RSS 22MF (5X11) TP 151 C MYLAR CM201~202 CMXM1H183J 50V 0.018MF J
94 C ELECTRO CE202 CEXF1H100V 50V RSS 10MF (5X11) TP 152 C MYLAR CM405~408 CMXM1H104J 50V 0.1MF J
95 C ELECTRO CE203 CEXF1H479V 50V RSS 4.7MF (5X11) TP 153 C MYLAR CM409~410 CMXM1H562J 50V 5600 PF J
96 C ELECTRO CE204 CEXF1E330V 25V RSS 33MF (5X11) TP 154 C MYLAR CM603~604 CMXM1H223J 50V 0.022MF J
97 C ELECTRO CE206 CEXF1H109V 50V RSS 1MF (5X11) TP 155 C MYLAR CM605~606 CMXM1H102J 50V 0.001MF J (TP)
98 C ELECTRO CE207 CEXF1H478V 50V RSS 0.47MF (5X11) TP 156 C MYLAR CM609~610 CMXM1H153J 50V 0.015MF J (TP)
99 C ELECTRO CE208~210 CEXF1H109V 50V RSS 1MF (5X11) TP 157 C MYLAR CM611 CMXM1H223J 50V 0.022MF J
100 C ELECTRO CE211 CEXF1H339V 50V RSS 3.3MF (5X11) TP 158 C MYLAR CM612 CMXM1H332J 50V 3300 PF J
101 C ELECTRO CE214 CEXF1E470V 25V RSS 47MF (5X11) TP 159 C MYLAR CM613 CMXM1H153J 50V 0.015MF J (TP)
102 C ELECTRO CE401~408 CEXF1H229V 50V RSS 2.2MF (5X11) TP 160 C MYLAR CM614 CMXM1H182J 50V 1800PF J
103 C ELECTRO CE411~416 CEXF1H229V 50V RSS 2.2MF (5X11) TP 161 C MYLAR CM618~619 CMXM1H683J 50V 0.068 MF J
104 C ELECTRO CE417 CEXF1E221V 25V RSS 220MF (8X11.5) TP 162 C MYLAR CM801~802 CMXM1H104J 50V 0.1MF J
105 C ELECTRO CE418 CEXF1H100V 50V RSS 10MF (5X11) TP 163 C MYLAR CM803~804 CMXM1H473J 50V 0.047MF J
106 C ELECTRO CE501 CEXF1C101V 16V RSS 100MF (6.3X11) TP 164 C MYLAR CM901~904 CMXM1H223J 50V 0.022MF J
107 C ELECTRO CE502 CEXF1E330V 25V RSS 33MF (5X11) TP 165 C MYLAR CM916~918 CMXM1H223J 50V 0.022MF J
108 C ELECTRO CE503 CEXF1H109V 50V RSS 1MF (5X11) TP 166 C MYLAR CM921~923 CMXM1H223J 50V 0.022MF J
109 C ELECTRO CE504 CEXF1C101V 16V RSS 100MF (6.3X11) TP 167 CONN AS CN401 9736407600 PIN BASE 53095-1310 13P
110 C ELECTRO CE505 CEXF1H479V 50V RSS 4.7MF (5X11) TP 168 CONN PIN CN402 9736407800 53095-1010 10PIN ANGLE
111 C ELECTRO CE507 CEXF1H338V 50V RSS 0.33MF (5X11) TP 169 CONN AS CN501 9738840800 FFC 16P P1.0X250MM R
112 C ELECTRO CE508 CEXF1E470V 25V RSS 47MF (5X11) TP 170 CONN AS CN601 9738835000 UL 2851 #28X2C0 3P 260MM
113 C ELECTRO CE509~510 CEXF1H479V 50V RSS 4.7MF (5X11) TP 171 CONN AS CN602 9728802100 UL2547 #28X3CO 4P
114 C ELECTRO CE511 CEXF1H229V 50V RSS 2.2MF (5X11) TP 172 CONN AS CN603 9738834900 UL 2468 #26 4P+3P+2P 360
115 C ELECTRO CE512 CEXF1H100V 50V RSS 10MF (5X11) TP 173 CONN AS CN605 9738834700 UL 1007 #26 1P 110MM
116 C ELECTRO CE513~514 CEXF1H479V 50V RSS 4.7MF (5X11) TP 174 CONN WAFER CW101 9CD6258800 2P S2B-XH-A
117 C ELECTRO CE515~516 CEXF1H478V 50V RSS 0.47MF (5X11) TP 175 CONN WAFER CW501 9738842900 16P FFC PIT1.0
118 C ELECTRO CE517 CEYF1C471V 16V RSS 470MF 10X12.5 176 CONN WAFER CW502 9CD6259500 2001-WS-6P
119 C ELECTRO CE518 CEYF1C102V 16V RSS 1000MF (10X20) 177 CONN WAFER CW503 9CD6259400 2001-WS-12P
120 C ELECTRO CE519 CEXF1C101V 16V RSS 100MF (6.3X11) TP 178 CONN AS CW601 9738835000 UL 2851 #28X2C0 3P 260MM
121 C ELECTRO CE520 CEXF1H100V 50V RSS 10MF (5X11) TP 179 CONN AS CW602 9728802100 UL2547 #28X3CO 4P
122 C ELECTRO CE521~522 CEXF1C101V 16V RSS 100MF (6.3X11) TP 180 CONN AS CW603 9738834900 UL 2468 #26 4P+3P+2P 360
123 C ELECTRO CE523 CEXF1C221V 16V RSS 220MF (8X11.5) TP 181 CONN AS CW605 9738834700 UL 1007 #26 1P 110MM
124 C ELECTRO CE524 CEXF1C101V 16V RSS 100MF (6.3X11) TP 182 CONN AS CW705 9728802700 #26 13P FLAT 220MM P=2.5
125 C ELECTRO CE601~602 CEXF1E470V 25V RSS 47MF (5X11) TP 183 CONN AS CW709 9728802900 #26 3P FLAT 100MM P=2.0
126 C ELECTRO CE603~604 CEXF1H100V 50V RSS 10MF (5X11) TP 184 CONN AS CW991 9738833900 #22 8P BOARD-IN 350MM
127 C ELECTRO CE605 CEXF1E470V 25V RSS 47MF (5X11) TP 185 DIODE D201 DZN4148--- 1N4148 AUTO 52MM
128 C ELECTRO CE606 CEXF1H229V 50V RSS 2.2MF (5X11) TP 186 DIODE D401~402 DZN4148--- 1N4148 AUTO 52MM
129 C ELECTRO CE608 CEXF1E470V 25V RSS 47MF (5X11) TP 187 DIODE D472~473 DZN4148--- 1N4148 AUTO 52MM
130 C ELECTRO CE609 CEXF1H339V 50V RSS 3.3MF (5X11) TP 188 DIODE D501 DZN4148--- 1N4148 AUTO 52MM
131 C ELECTRO CE610 CEXF1H100V 50V RSS 10MF (5X11) TP 189 DIODE D602~610 DZN4148--- 1N4148 AUTO 52MM
132 C ELECTRO CE611~612 CEXF1E470V 25V RSS 47MF (5X11) TP 190 DIODE D801~802 DZN4148--- 1N4148 AUTO 52MM
133 C ELECTRO CE613~614 CEXF1H100V 50V RSS 10MF (5X11) TP 191 DIODE D901~902 D1N4001--- 1N4001
134 C ELECTRO CE615~616 CEXF1H109V 50V RSS 1MF (5X11) TP 192 DIODE D904~907 DRL202---- RL202
135 C ELECTRO CE617 CEXF1H339V 50V RSS 3.3MF (5X11) TP 193 DIODE D911~912 D1N4001--- 1N4001
136 C ELECTRO CE618 CEXF1E470V 25V RSS 47MF (5X11) TP 194 DIODE ZENER DZ601~602 DZTZ6R2B-- MTZ6.2B
137 C ELECTRO CE619~620 CEXF1H229V 50V RSS 2.2MF (5X11) TP 195 DIODE ZENER DZ901 DZTZ30B--- MTZ30B
138 C ELECTRO CE621~623 CEXF1E470V 25V RSS 47MF (5X11) TP 196 DIODE ZENER DZ902 DZTZ6R2B-- MTZ6.2B
139 C ELECTRO CE624 CEXF1H229V 50V RSS 2.2MF (5X11) TP 197 IC IC201 1LA1833N-- LA1833N
140 C ELECTRO CE625~626 CEXF1E470V 25V RSS 47MF (5X11) TP 198 IC IC202 1LC72131D- LC72131D
141 C ELECTRO CE801~803 CEXF1H109V 50V RSS 1MF (5X11) TP 199 IC REGULATOR IC205 1KA78L05AZ KA78L05AZ
142 C ELECTRO CE804~805 CEXF1H100V 50V RSS 10MF (5X11) TP 200 IC IC401 1TDA7440D- TDA7440D
- 18 -
