Daewoo AMI-V225M - Page 22

Electrical Parts List
LOCATIO
N
PART-CODE PART-DESC REMARKSPART-DESC REMARKS NO PART-NAMENO PART-NAME LOCATION PART-CODE
201 IC MOTOR DRIVE IC501 1BA5939S-- BA5939S 259 WIRE JUMPER JW546~547 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
202 IC CHIP RF IC502 1KB9223--- KB9223 RF+SSP+AF 260 WIRE JUMPER JW548 W581GY6095 AWG22 1/0.65 SN 6 AUTO
203 IC CHIP DSP IC503 1KS9286B-- KS9286B DSP+DAC 261 WIRE JUMPER JW549 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
204 IC IC601 1TA8189N-- TA8189N 262 WIRE JUMPER JW550 W581GY6095 AWG22 1/0.65 SN 6 AUTO
205 IC SWITCHING IC602 1BA7755A-- BA7755A (HEAD SW) 263 COIL BEAD JW551 5LX159P829 1.5UH MIN
206 IC IC801 1TDA7499-- TDA7499 264 WIRE JUMPER JW553~555 W581GY1005 AWG22 1/0.65 SN 10 AUTO
207 IC IC901 1L4959---- L4959 265 WIRE JUMPER JW556~557 W581GY6095 AWG22 1/0.65 SN 6 AUTO
208 JACK ANT J001 9736321900 PAT645 266 WIRE JUMPER JW558~559 W581GY1005 AWG22 1/0.65 SN 10 AUTO
209 JACK RCA J401 9CD6313700 S-436P 267 WIRE JUMPER JW560~564 W581GY6095 AWG22 1/0.65 SN 6 AUTO
210 JACK HEADPHONE J801 9766319501 HTJ-064-05B GOLD 268 WIRE JUMPER JW565 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO
211 JACK SPEAKER J802 9736320500 CJ-9007-040 269 WIRE JUMPER JW566 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
212 WIRE JUMPER JW201~202 W581GY6095 AWG22 1/0.65 SN 6 AUTO 270 WIRE JUMPER JW567~568 W581GY6095 AWG22 1/0.65 SN 6 AUTO
213 WIRE JUMPER JW203 W581GY1005 AWG22 1/0.65 SN 10 AUTO 271 WIRE JUMPER JW569 W581GY1505 AWG22 1/0.65 GY 15 AUTO
214 WIRE JUMPER JW206 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO 272 WIRE JUMPER JW570 W581GY1005 AWG22 1/0.65 SN 10 AUTO
215 WIRE JUMPER JW207 W581GY1005 AWG22 1/0.65 SN 10 AUTO 273 WIRE JUMPER JW573 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO
216 WIRE JUMPER JW208 W581GY6095 AWG22 1/0.65 SN 6 AUTO 274 WIRE JUMPER JW574~576 W581GY6095 AWG22 1/0.65 SN 6 AUTO
217 WIRE JUMPER JW209 W581GY1005 AWG22 1/0.65 SN 10 AUTO 275 WIRE JUMPER JW578 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
218 WIRE JUMPER JW210~211 W581GY6095 AWG22 1/0.65 SN 6 AUTO 276 WIRE JUMPER JW579 W581GY1505 AWG22 1/0.65 GY 15 AUTO
219 WIRE JUMPER JW212 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO 277 WIRE JUMPER JW580 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
220 WIRE JUMPER JW213 W581GY1005 AWG22 1/0.65 SN 10 AUTO 278 WIRE JUMPER JW601 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
221 WIRE JUMPER JW214~215 W581GY6095 AWG22 1/0.65 SN 6 AUTO 279 WIRE JUMPER JW602 W581GY1005 AWG22 1/0.65 SN 10 AUTO
222 WIRE JUMPER JW217 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO 280 WIRE JUMPER JW603 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
223 WIRE JUMPER JW401 W581GY1505 AWG22 1/0.65 GY 15 AUTO 281 WIRE JUMPER JW604 W581GY1505 AWG22 1/0.65 GY 15 AUTO
224 WIRE JUMPER JW402 W581GY1005 AWG22 1/0.65 SN 10 AUTO 282 WIRE JUMPER JW605~606 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
225 WIRE JUMPER JW403 W581GY1505 AWG22 1/0.65 GY 15 AUTO 283 WIRE JUMPER JW608 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
226 COIL BEAD JW404 5LX159P829 1.5UH MIN 284 WIRE JUMPER JW609 W581GY1505 AWG22 1/0.65 GY 15 AUTO
227 WIRE JUMPER JW405 W581GY1005 AWG22 1/0.65 SN 10 AUTO 285 WIRE JUMPER JW610 W581GY6095 AWG22 1/0.65 SN 6 AUTO
228 WIRE JUMPER JW406~408 W581GY6095 AWG22 1/0.65 SN 6 AUTO 286 WIRE JUMPER JW611 W581GY15J5 AWG22 1/0.65 SN 15.5 AUTO
229 WIRE JUMPER JW409 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO 287 WIRE JUMPER JW612 W581GY1005 AWG22 1/0.65 SN 10 AUTO
230 WIRE JUMPER JW410 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO 288 WIRE JUMPER JW613~617 W581GY6095 AWG22 1/0.65 SN 6 AUTO
231 DIODE JW411 DZN4148--- 1N4148 AUTO 52MM 289 WIRE JUMPER JW619 W581GY6095 AWG22 1/0.65 SN 6 AUTO
232 WIRE JUMPER JW412~413 W581GY6095 AWG22 1/0.65 SN 6 AUTO 290 WIRE JUMPER JW620 W581GY1005 AWG22 1/0.65 SN 10 AUTO
233 WIRE JUMPER JW415 W581GY6095 AWG22 1/0.65 SN 6 AUTO 291 WIRE JUMPER JW621 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
234 WIRE JUMPER JW416~417 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO 292 WIRE JUMPER JW622~625 W581GY6095 AWG22 1/0.65 SN 6 AUTO
235 WIRE JUMPER JW503~504 W581GY1005 AWG22 1/0.65 SN 10 AUTO 293 WIRE JUMPER JW626 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
236 WIRE JUMPER JW505~506 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO 294 WIRE JUMPER JW627 W581GY1005 AWG22 1/0.65 SN 10 AUTO
237 R CARBON FILM JW507 RD-AZ103J- 1/6 10K OHM J 295 WIRE JUMPER JW628~630 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
238 WIRE JUMPER JW508~509 W581GY1505 AWG22 1/0.65 GY 15 AUTO 296 WIRE JUMPER JW632 W581GY6095 AWG22 1/0.65 SN 6 AUTO
239 WIRE JUMPER JW510 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO 297 WIRE JUMPER JW634~635 W581GY6095 AWG22 1/0.65 SN 6 AUTO
240 WIRE JUMPER JW511~512 W581GY1005 AWG22 1/0.65 SN 10 AUTO 298 WIRE JUMPER JW636 W581GY1005 AWG22 1/0.65 SN 10 AUTO
241 WIRE JUMPER JW513 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO 299 WIRE JUMPER JW637~638 W581GY6095 AWG22 1/0.65 SN 6 AUTO
242 WIRE JUMPER JW514~515 W581GY1005 AWG22 1/0.65 SN 10 AUTO 300 WIRE JUMPER JW639~640 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
243 WIRE JUMPER JW516 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO 301 WIRE JUMPER JW802 W581GY1005 AWG22 1/0.65 SN 10 AUTO
244 WIRE JUMPER JW517~518 W581GY6095 AWG22 1/0.65 SN 6 AUTO 302 WIRE JUMPER JW803 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
245 WIRE JUMPER JW519~520 W581GY1505 AWG22 1/0.65 GY 15 AUTO 303 WIRE JUMPER JW804 W581GY1005 AWG22 1/0.65 SN 10 AUTO
246 WIRE JUMPER JW521 W581GY1005 AWG22 1/0.65 SN 10 AUTO 304 WIRE JUMPER JW805 W581GY6095 AWG22 1/0.65 SN 6 AUTO
247 WIRE JUMPER JW522 W581GY6095 AWG22 1/0.65 SN 6 AUTO 305 WIRE JUMPER JW806 W581GY1505 AWG22 1/0.65 GY 15 AUTO
248 WIRE JUMPER JW524 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO 306 WIRE JUMPER JW807 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
249 WIRE JUMPER JW525 W581GY1005 AWG22 1/0.65 SN 10 AUTO 307 WIRE JUMPER JW808~809 W581GY1505 AWG22 1/0.65 GY 15 AUTO
250 WIRE JUMPER JW526 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO 308 WIRE JUMPER JW810 W581GY6095 AWG22 1/0.65 SN 6 AUTO
251 WIRE JUMPER JW528 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO 309 WIRE JUMPER JW811 W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO
252 WIRE JUMPER JW529 W581GY6095 AWG22 1/0.65 SN 6 AUTO 310 WIRE JUMPER JW812 W581GY6095 AWG22 1/0.65 SN 6 AUTO
253 WIRE JUMPER JW530~534 W581GY1005 AWG22 1/0.65 SN 10 AUTO 311 WIRE JUMPER JW814 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO
254 WIRE JUMPER JW535~537 W581GY6095 AWG22 1/0.65 SN 6 AUTO 312 WIRE JUMPER JW815 W581GY6095 AWG22 1/0.65 SN 6 AUTO
255 WIRE JUMPER JW538 W581GY1005 AWG22 1/0.65 SN 10 AUTO 313 WIRE JUMPER JW901 W581GY1505 AWG22 1/0.65 GY 15 AUTO
256 COIL BEAD JW539 5LX159P829 1.5UH MIN 314 WIRE JUMPER JW903~904 W581GY1505 AWG22 1/0.65 GY 15 AUTO
257 WIRE JUMPER JW540~542 W581GY1005 AWG22 1/0.65 SN 10 AUTO 315 WIRE JUMPER JW905 W581GY1005 AWG22 1/0.65 SN 10 AUTO
258 WIRE JUMPER JW543~545 W581GY6095 AWG22 1/0.65 SN 6 AUTO 316 WIRE JUMPER JW906 W581GY7595 AWG22 1/0.65 SN 7.5 AUTO
- 19 -
