Electrical Parts List
LOCATIO
PART-CODE PART-DESC REMARKSPART-DESC REMARKS NO PART-NAMENO PART-NAME LOCATION PART-CODE
317 WIRE JUMPER JW907~908 W581GY1505 AWG22 1/0.65 GY 15 AUTO 375 R CARBON FILM R210 RD-AZ682J- 1/6 6.8K OHM J
318 WIRE JUMPER JW912 W581GY1005 AWG22 1/0.65 SN 10 AUTO 376 R CARBON FILM R211 RD-AZ100J- 1/6 10 OHM J
319 WIRE JUMPER JW915 W581GY1005 AWG22 1/0.65 SN 10 AUTO 377 R CARBON FILM R212~213 RD-AZ182J- 1/6 1.8K OHM J
320 WIRE JUMPER JW918 W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO 378 R CARBON FILM R214~215 RD-AZ332J- 1/6 3.3K OHM J
321 WIRE JUMPER JW919 W581GY1505 AWG22 1/0.65 GY 15 AUTO 379 R CARBON FILM R216 RD-AZ473J- 1/6 47K OHM J
322 WIRE JUMPER JW922 W581GY1505 AWG22 1/0.65 GY 15 AUTO 380 WIRE JUMPER R217~218 W581GY6095 AWG22 1/0.65 SN 6 AUTO
323 COIL PEAKING L001 5CPZ100K02 10UH K (AXIAL 3.5MM) 381 R CARBON FILM R221 RD-AZ563J- 1/6 56K OHM J
324 AM RF UNIT L101 5LR0000834 RBW07VB-K5024 382 R CARBON FILM R251 RD-AZ102J- 1/6 1K OHM J
325 COIL L201~202 5P076068-- 6068MPX 383 R CARBON FILM R252 RD-AZ470J- 1/6 47 OHM J
326 COIL PEAKING L251 5CPZ100K02 10UH K (AXIAL 3.5MM) 384 R CARBON FILM R253 RD-AZ222J- 1/6 2.2K OHM J
327 COIL OSC L601 5L00000500 0500 10X10 BK 385 R CARBON FILM R254 RD-AZ103J- 1/6 10K OHM J
328 WIRE JUMPER L602~603 W581GY5095 AWG22 1/0.65 SN 5 AUTO 386 R CARBON FILM R255 RD-AZ100J- 1/6 10 OHM J
329 TR Q001 TZTC3194Y- KTC3194Y 387 R CARBON FILM R256 RD-AZ102J- 1/6 1K OHM J
330 TR Q003 TZRA107M-- KRA107M (KSR2006) 388 R CARBON FILM R257~258 RD-AZ103J- 1/6 10K OHM J
331 TR Q501 TZTA1266Y- KTA1266Y- (AUTO)(1015Y) 389 R CARBON FILM R259 RD-AZ123J- 1/6 12K OHM J
332 TR Q502 TZTA1273Y- KTA1273Y(966Y) 390 R CARBON FILM R260~263 RD-AZ102J- 1/6 1K OHM J
333 TR Q503 TZTC3198Y- KTC3198Y-(1815Y) (AUTO) 391 R CARBON FILM R264~265 RD-AZ222J- 1/6 2.2K OHM J
334 FET Q601~602 TKTK117Y-- KTK117(Y) 392 R CARBON FILM R290 RD-AZ105J- 1/6 1M OHM J
335 TR Q603~604 TZTA1266Y- KTA1266Y- (AUTO)(1015Y) 393 R CARBON FILM R401~402 RD-AZ822J- 1/6 8.2K OHM J
336 TR Q605 TZTC3198Y- KTC3198Y-(1815Y) (AUTO) 394 R CARBON FILM R403~404 RD-AZ153J- 1/6 15K OHM J
337 TR Q607 TZTC3198Y- KTC3198Y-(1815Y) (AUTO) 395 R CARBON FILM R405~406 RD-AZ392J- 1/6 3.9K OHM J
338 TR Q608 TKRC107M-- KRC107-M TAPPING(KSR1006) 396 R CARBON FILM R407~408 RD-AZ682J- 1/6 6.8K OHM J
339 TR Q609 TKRA111M-- KRA111-M TAPPING(KSR2010) 397 R CARBON FILM R409~410 RD-AZ102J- 1/6 1K OHM J
340 TR Q610 TZTC3198Y- KTC3198Y-(1815Y) (AUTO) 398 R CARBON FILM R411~412 RD-AZ153J- 1/6 15K OHM J
341 TR Q611 TZTA1266Y- KTA1266Y- (AUTO)(1015Y) 399 R CARBON FILM R413~414 RD-AZ182J- 1/6 1.8K OHM J
342 TR Q612 TZRC111M-- KRC111M 400 R CARBON FILM R415~416 RD-AZ392J- 1/6 3.9K OHM J
343 TR Q613 TZTC3198Y- KTC3198Y-(1815Y) (AUTO) 401 R CARBON FILM R421~422 RD-AZ104J- 1/6 100K OHM J
344 TR Q614 TKRC107M-- KRC107-M TAPPING(KSR1006) 402 R CARBON FILM R423~424 RD-AZ102J- 1/6 1K OHM J
345 TR Q615~620 TZTC3198Y- KTC3198Y-(1815Y) (AUTO) 403 R CARBON FILM R425~426 RD-AZ104J- 1/6 100K OHM J
346 TR Q621 TZTA1273Y- KTA1273Y(966Y) 404 R CARBON FILM R427~428 RD-AZ562J- 1/6 5.6K OHM J
347 TR Q626 TZTA1273Y- KTA1273Y(966Y) 405 R CARBON FILM R431~432 RD-AZ102J- 1/6 1K OHM J
348 TR Q627 TZRC111M-- KRC111M 406 R CARBON FILM R433~434 RD-AZ104J- 1/6 100K OHM J
349 TR Q632~636 TZRC111M-- KRC111M 407 R CARBON FILM R436~437 RD-AZ101J- 1/6 100 OHM J
350 TR Q801~802 TZTC3198Y- KTC3198Y-(1815Y) (AUTO) 408 R CARBON FILM R439~440 RD-AZ473J- 1/6 47K OHM J
351 TR Q803 TZRA111M-- KRA111M 409 R CARBON FILM R441 RD-AZ221J- 1/6 220 OHM J
352 TR Q804 TZTC3198Y- KTC3198Y-(1815Y) (AUTO) 410 R CARBON FILM R442 RD-AZ104J- 1/6 100K OHM J
353 TR Q805 TZRA111M-- KRA111M 411 R CARBON FILM R443~444 RD-AZ474J- 1/6 470K OHM J
354 TR Q901 TZTA1274Y- KTA1274Y- 412 R CARBON FILM R501 RD-AZ124J- 1/6 120K OHM J
355 WIRE JUMPER R002 W581GY6095 AWG22 1/0.65 SN 6 AUTO 413 R CARBON FILM R502~505 RD-AZ393J- 1/6 39K OHM J
356 R CARBON FILM R003 RD-AZ151J- 1/6 150 OHM J 414 R CARBON FILM R506 RD-AZ124J- 1/6 120K OHM J
357 R CARBON FILM R004 RD-AZ100J- 1/6 10 OHM J 415 R CARBON FILM R507 RD-AZ101J- 1/6 100 OHM J
358 R CARBON FILM R005 RD-AZ332J- 1/6 3.3K OHM J 416 R CARBON FILM R508~509 RD-AZ103J- 1/6 10K OHM J
359 R CARBON FILM R006 RD-AZ681J- 1/6 680 OHM J 417 R CARBON FILM R510 RD-AZ220J- 1/6 22 OHM J
360 R CARBON FILM R007 RD-AZ331J- 1/6 330 OHM J 418 R CARBON FILM R511 RD-AZ824J- 1/6 820K OHM J
361 R CARBON FILM R008 RD-AZ101J- 1/6 100 OHM J 419 R CARBON FILM R512 RD-AZ100J- 1/6 10 OHM J
362 R CARBON FILM R101 RD-AZ472J- 1/6 4.7K OHM J 420 R CARBON FILM R513 RD-AZ474J- 1/6 470K OHM J
363 R CARBON FILM R103~105 RD-AZ472J- 1/6 4.7K OHM J 421 R CARBON FILM R514 RD-AZ100J- 1/6 10 OHM J
364 R CARBON FILM R106 RD-AZ332J- 1/6 3.3K OHM J 422 R CARBON FILM R515 RD-AZ682J- 1/6 6.8K OHM J
365 R CARBON FILM R107 RD-AZ223J- 1/6 22K OHM J 423 R CARBON FILM R516 RD-AZ153J- 1/6 15K OHM J
366 R CARBON FILM R109 RD-AZ104J- 1/6 100K OHM J 424 R CARBON FILM R517 RD-AZ273J- 1/6 27K OHM J
367 R CARBON FILM R201 RD-AZ682J- 1/6 6.8K OHM J 425 R CARBON FILM R518 RD-AZ562J- 1/6 5.6K OHM J
368 R CARBON FILM R202 RD-AZ473J- 1/6 47K OHM J 426 R CARBON FILM R519~520 RD-AZ103J- 1/6 10K OHM J
369 R CARBON FILM R203 RD-AZ822J- 1/6 8.2K OHM J 427 R CARBON FILM R521 RD-AZ154J- 1/6 150K OHM J
370 R CARBON FILM R204 RD-AZ562J- 1/6 5.6K OHM J 428 R CARBON FILM R522~523 RD-AZ562J- 1/6 5.6K OHM J
371 R CARBON FILM R205~206 RD-AZ102J- 1/6 1K OHM J 429 R CARBON FILM R524 RD-AZ102J- 1/6 1K OHM J
372 R CARBON FILM R207 RD-AZ121J- 1/6 120 OHM J 430 R CARBON FILM R525 RD-AZ104J- 1/6 100K OHM J
373 R CARBON FILM R208 RD-AZ332J- 1/6 3.3K OHM J 431 R CARBON FILM R526 RD-AZ100J- 1/6 10 OHM J
374 R CARBON FILM R209 RD-AZ472J- 1/6 4.7K OHM J 432 R CARBON FILM R527 RD-AZ474J- 1/6 470K OHM J
