Daewoo AMI-V225M - Page 24

Electrical Parts List
LOCATIO
N
PART-CODE PART-DESC REMARKSPART-DESC REMARKS NO PART-NAMENO PART-NAME LOCATION PART-CODE
433 R CARBON FILM R528 RD-AZ100J- 1/6 10 OHM J 491 R CARBON FILM R635~636 RD-AZ561J- 1/6 560 OHM J
434 R CARBON FILM R529~530 RD-AZ562J- 1/6 5.6K OHM J 492 R CARBON FILM R637~638 RD-AZ184J- 1/6 180K OHM J
435 R CARBON FILM R531 RD-AZ103J- 1/6 10K OHM J 493 R CARBON FILM R639~640 RD-AZ472J- 1/6 4.7K OHM J
436 R CARBON FILM R532 RD-AZ683J- 1/6 68K OHM J 494 R CARBON FILM R641 RD-AZ103J- 1/6 10K OHM J
437 R CARBON FILM R533 RD-AZ823J- 1/6 82K OHM J 495 R CARBON FILM R643~644 RD-AZ223J- 1/6 22K OHM J
438 R CARBON FILM R534 RD-AZ562J- 1/6 5.6K OHM J 496 R CARBON FILM R645~648 RD-AZ472J- 1/6 4.7K OHM J
439 R CARBON FILM R535 RD-AZ183J- 1/6 18K OHM J 497 R CARBON FILM R649 RD-AZ224J- 1/6 220K OHM J
440 R CARBON FILM R536 RD-AZ563J- 1/6 56K OHM J 498 R CARBON FILM R650 RD-AZ334J- 1/6 330K OHM J
441 R CARBON FILM R537 RD-AZ273J- 1/6 27K OHM J 499 R CARBON FILM R651 RD-AZ103J- 1/6 10K OHM J
442 R CARBON FILM R538 RD-AZ683J- 1/6 68K OHM J 500 R CARBON FILM R652 RD-AZ479J- 1/6 4.7 OHM J
443 R CARBON FILM R539 RD-AZ184J- 1/6 180K OHM J 501 R CARBON FILM R653 RD-AZ473J- 1/6 47K OHM J
444 R CARBON FILM R540 RD-AZ153J- 1/6 15K OHM J 502 R CARBON FILM R654 RD-4Z221J- 1/4 220 OHM J
445 R CARBON FILM R541 RD-AZ103J- 1/6 10K OHM J 503 R CARBON FILM R655 RD-AZ102J- 1/6 1K OHM J
446 R CARBON FILM R542 RD-AZ683J- 1/6 68K OHM J 504 R CARBON FILM R656 RD-AZ333J- 1/6 33K OHM J
447 R CARBON FILM R543 RD-AZ103J- 1/6 10K OHM J 505 R CARBON FILM R657 RD-AZ470J- 1/6 47 OHM J
448 R CARBON FILM R544 RD-AZ473J- 1/6 47K OHM J 506 R CARBON FILM R658 RD-AZ473J- 1/6 47K OHM J
449 R CARBON FILM R545~546 RD-AZ273J- 1/6 27K OHM J 507 R CARBON FILM R659~660 RD-AZ102J- 1/6 1K OHM J
450 R CARBON FILM R547 RD-AZ683J- 1/6 68K OHM J 508 R CARBON FILM R661 RD-AZ104J- 1/6 100K OHM J
451 R CARBON FILM R548 RD-AZ333J- 1/6 33K OHM J 509 R CARBON FILM R662 RD-AZ103J- 1/6 10K OHM J
452 R CARBON FILM R549 RD-AZ104J- 1/6 100K OHM J 510 R CARBON FILM R663 RD-AZ331J- 1/6 330 OHM J
453 R CARBON FILM R550 RD-AZ333J- 1/6 33K OHM J 511 R CARBON FILM R664 RD-AZ472J- 1/6 4.7K OHM J
454 R CARBON FILM R551~552 RD-AZ103J- 1/6 10K OHM J 512 R CARBON FILM R665 RD-AZ822J- 1/6 8.2K OHM J
455 R CARBON FILM R553 RD-AZ154J- 1/6 150K OHM J 513 R CARBON FILM R667 RD-AZ472J- 1/6 4.7K OHM J
456 R CARBON FILM R554 RD-AZ105J- 1/6 1M OHM J 514 R CARBON FILM R668 RD-AZ561J- 1/6 560 OHM J
457 R CARBON FILM R555~556 RD-2Y150J- 1/2 15 OHM J 515 R CARBON FILM R669 RD-AZ103J- 1/6 10K OHM J
458 R CARBON FILM R557 RD-AZ104J- 1/6 100K OHM J 516 R CARBON FILM R670~671 RD-AZ472J- 1/6 4.7K OHM J
459 R CARBON FILM R558 RD-AZ102J- 1/6 1K OHM J 517 R CARBON FILM R672 RD-AZ101J- 1/6 100 OHM J
460 R CARBON FILM R559 RD-AZ822J- 1/6 8.2K OHM J 518 R CARBON FILM R673 RD-AZ105J- 1/6 1M OHM J
461 R CARBON FILM R560 RD-AZ123J- 1/6 12K OHM J 519 R CARBON FILM R674~675 RD-AZ103J- 1/6 10K OHM J
462 R CARBON FILM R561 RD-AZ273J- 1/6 27K OHM J 520 R CARBON FILM R676 RD-AZ105J- 1/6 1M OHM J
463 R CARBON FILM R562~563 RD-AZ332J- 1/6 3.3K OHM J 521 R CARBON FILM R677 RD-AZ822J- 1/6 8.2K OHM J
464 R CARBON FILM R564 RD-AZ102J- 1/6 1K OHM J 522 R CARBON FILM R683 RD-AZ103J- 1/6 10K OHM J
465 R CARBON FILM R567 RD-AZ102J- 1/6 1K OHM J 523 R CARBON FILM R684 RD-AZ392J- 1/6 3.9K OHM J
466 R CARBON FILM R568 RD-AZ221J- 1/6 220 OHM J 524 R CARBON FILM R685~686 RD-AZ102J- 1/6 1K OHM J
467 R CARBON FILM R569~570 RD-AZ104J- 1/6 100K OHM J 525 R CARBON FILM R688 RD-AZ101J- 1/6 100 OHM J
468 R CARBON FILM R571 RD-AZ472J- 1/6 4.7K OHM J 526 R CARBON FILM R694~695 RD-AZ101J- 1/6 100 OHM J
469 R CARBON FILM R572~573 RD-AZ104J- 1/6 100K OHM J 527 R CARBON FILM R696 RD-AZ333J- 1/6 33K OHM J
470 R CARBON FILM R574~579 RD-AZ472J- 1/6 4.7K OHM J 528 R CARBON FILM R803~804 RD-AZ102J- 1/6 1K OHM J
471 R CARBON FILM R580~581 RD-AZ103J- 1/6 10K OHM J 529 R CARBON FILM R805~806 RD-AZ563J- 1/6 56K OHM J
472 R CARBON FILM R582 RD-AZ101J- 1/6 100 OHM J 530 R CARBON FILM R807~808 RD-AZ152J- 1/6 1.5K OHM J
473 R CARBON FILM R601~604 RD-AZ102J- 1/6 1K OHM J 531 R CARBON FILM R809~812 RD-4Z100J- 1/4 10 OHM J
474 R CARBON FILM R605~606 RD-AZ820J- 1/6 82 OHM J 532 R CARBON FILM R813 RD-AZ103J- 1/6 10K OHM J
475 R CARBON FILM R607~608 RD-AZ683J- 1/6 68K OHM J 533 R CARBON FILM R815~818 RD-4Z102J- 1/4 1K OHM J
476 R CARBON FILM R609~610 RD-AZ682J- 1/6 6.8K OHM J 534 R CARBON FILM R821 RD-AZ154J- 1/6 150K OHM J
477 R CARBON FILM R611~612 RD-AZ272J- 1/6 2.7K OHM J 535 R CARBON FILM R823 RD-AZ104J- 1/6 100K OHM J
478 R CARBON FILM R613~614 RD-AZ102J- 1/6 1K OHM J 536 R CARBON FILM R824 RD-AZ473J- 1/6 47K OHM J
479 R CARBON FILM R615~616 RD-AZ223J- 1/6 22K OHM J 537 R CARBON FILM R825 RD-AZ103J- 1/6 10K OHM J
480 R CARBON FILM R617~618 RD-AZ272J- 1/6 2.7K OHM J 538 WIRE JUMPER R827~830 W581GY1005 AWG22 1/0.65 SN 10 AUTO
481 R CARBON FILM R619~620 RD-AZ103J- 1/6 10K OHM J 539 R CARBON FILM R831~832 RD-AZ102J- 1/6 1K OHM J
482 R CARBON FILM R621 RD-AZ333J- 1/6 33K OHM J 540 R CARBON FILM R910 RD-AZ103J- 1/6 10K OHM J
483 R CARBON FILM R622 RD-AZ105J- 1/6 1M OHM J 541 R CARBON FILM R911 RD-AZ223J- 1/6 22K OHM J
484 R CARBON FILM R623 RD-AZ683J- 1/6 68K OHM J 542 R CARBON FILM R912~913 RD-AZ103J- 1/6 10K OHM J
485 R CARBON FILM R624 RD-AZ103J- 1/6 10K OHM J 543 R CARBON FILM R914 RD-AZ223J- 1/6 22K OHM J
486 R CARBON FILM R625~626 RD-AZ184J- 1/6 180K OHM J 544 R CARBON FILM R915 RD-AZ473J- 1/6 47K OHM J
487 R CARBON FILM R627~628 RD-AZ151J- 1/6 150 OHM J 545 R CARBON FILM R916 RD-AZ103J- 1/6 10K OHM J
488 R CARBON FILM R629~630 RD-AZ224J- 1/6 220K OHM J 546 R CARBON FILM R921 RD-AZ100J- 1/6 10 OHM J
489 R CARBON FILM R631~632 RD-AZ563J- 1/6 56K OHM J 547 R CARBON FILM R922 RD-AZ332J- 1/6 3.3K OHM J
490 R CARBON FILM R633~634 RD-AZ392J- 1/6 3.9K OHM J 548 R CARBON FILM R923 RD-AZ103J- 1/6 10K OHM J
- 21 -
