Electrical Parts List
PART-DESC REMARKSNO PART-NAME LOCATION PART-CODE
549 R CARBON FILM R933~934 RD-AZ221J- 1/6 220 OHM J
550 R CARBON FILM R939~940 RD-AZ109J- 1/6 1 OHM J
551 R FUSIBLE RF901~902 RF-2F478J- 1/2 0.47 OHM J
552 R SEMI FIXED RV601 RV1417222- 1/10 2.2K OHM B V6EK-PV1S
553 SW TACT SW723 5S50101008 KPT-1105V 1C-1P
554 TUNER PACK TU001 9737613500 FTE4-401TC
555 CONN AS W600 9738834700 UL 1007 #26 1P 110MM
556 CONN AS W601 9738834700 UL 1007 #26 1P 110MM
557 C DISCRIMINATOR XC201 5P107MG86C CDA10.7MG86N-C
558 X-TAL XC251 5XA7R20000 7.2M
559 RESONATOR CERA XC501 5PCSA16R93 CSA16.93MXZ04
560 RESONATOR XC701 5PCSA8MTZ- CSA8MTZ, 8MHZ
561 X-TAL XC702 5XA32R768- DT-38 32.768KHZ 20PPM
562 X-TAL XC703 5XA4R332M- 4.332M
1 PCB PT AS 12000 9CDC055510 AMI-208MV
2 PCB PT B991 9CD6582000 98X123
3 WIRE JUMPER CC995 W581GY1005 AWG22 1/0.65 SN 10 AUTO
4 CORD AC CD991 9736900200 KKP419C,KLCE-2F,0.75SQURE
5 C ELECTRO CE991 CEXF1E222V 25V RSS 2200MF (16X25) TP
6 CONN AS CN991 9738833900 #22 8P BOARD-IN 350MM
7 CONN AS CW708 9728802800 #26 3P FLAT 360MM P=2.5
8 DIODE D991~994 DZN4001A-- 1N4001A AUTO
9 DIODE D995 DZN4148--- 1N4148 AUTO 52MM
10 DIODE D996 DZN4001A-- 1N4001A AUTO
11 FUSE GLASS TUBE F902 5FSGB3112L SEMKO TL 0.315A 250V MF51
12 CLIP FUSE FC903~904 9734600700 FC-5N
13 IC IC991 1MC7805--- MC 7805 (KA7805)
14 WIRE JUMPER JW994 W581GY1005 AWG22 1/0.65 SN 10 AUTO
15 TRANS POWER PT991 5TP8060788 EI=60 230V 50HZ
16 TRANS POWER PT992 5TP8028829 EI=28X12 230V 50HZ
17 TR Q991 TZRC107M-- KRC107M(AUTO)
18 TR Q992 TZTC3198Y- KTC3198Y-(1815Y) (AUTO)
19 R METAL FILM R991 RN-2Y475J- 1/2 4.7M OHM J
20 R CARBON FILM R992 RD-4Z100J- 1/4 10 OHM J
21 R CARBON FILM R993 RD-AZ223J- 1/6 22K OHM J
22 R CARBON FILM R994 RD-AZ102J- 1/6 1K OHM J
23 SW RELAY RY991 5SC2001A01 SDT-S-105LMR
- 22 -
