46
1) Specifications
2) Specifications and Major Test Items
- Size of conductor: 1.5mm2
- Thickness of sheath: 0.8mm
- Thickness of insulator: 0.6mm
- External diameter of insulator: 8.4±1mm
3) Assembly
- Before fastening - After fastening
7. Specifications and Assembly of Cord Power Assy
Category Power Color Part Code Type Length Note
1 250V 16A GRAY 3611308100 H05W-F 3G 1.5mm
2
3.0 M -
2 250V 16A GRAY 3611308200 H05W-F 3G 1.5mm
2
5.0 M -
To Next Page
