4. DIRECTION FOR DISASSEMBLY
9
DIRECTION FOR DISASSEMBLY
DOOR LOCK SWITCH
1 Open the door and remove the clamp door as. 2 Separate the gasket from the cabinet front and remove
two screws.
DRAIN PUMP
3 Remove the door lock switch from the cabinet front .
1 Separate the cover pump from the cabinet front and
remove screw.
2 Lay the right-side of the washer on the floor. And sepa-
rate connectors and hose drain from the pump.
3 Remove the hose drain o from the pump.
To Next Page
