2. INSTALLATION
3
INSTALLATION
■ Removing transit bolts
1. Before operating the washer, remove the transit
bolts(3ea) along with the rubber.
• If the bolts are not removed, it may cause heavy
vibration, noise and malfunction.
2. Unscrew the 3 bolts with the 10mm hex wrench or
spanner or cross-tip screwdriver. Keep the 3 bolts for
a later time.
• When the appliance is transported, transit bolts will
be re-used.
3. Close the holes with sticker holders supplied.
■ Installation place requirement
• Level floor :
Allowable slope between the washer and floor is 1°.
• Electric outlet :
Must be with 1meter of either side of the washer.
Do not overload the outlet with more than one appliance.
• Additional clearance
Clearance between the washer and the wall is required.
(rear : about 10cm, left & right : about 2cm)
In case of built-in installation, the clearance between the top of
the washer and the under of the work-top is required.
(top : about 2cm)
■ Location of washer
Make sure that you have to do everything necessary for correct installation.
Install the washer on a solid and flat floor, if possible, in a corner of the room and the easily accessible place for an
engineer.
• Before placing the washer, if installed on tiles, apply a rubber mat under the adjustable leg.
• The washer must not be installed or stored in rooms below 0°C to avoid any damage from freezing.
• Do not insert pieces of wood, cardboard or similar materials under the adjustable leg to correct any unevenness.
• Do not place laundry products on top of the washer at all times.
• An air circulation around the washer must not be obstructed by carpets, rug etc.
