DIRECTION FOR DISASSEMBLY
UNIVERSAL MOTOR
1 Separate the box inlet as from the washer.
(Remove screws and hose inlet)
2 Remove the screw of the motor connector.
And separate the connector from the tub.
Firstly, you have to do from 1 to 5 of HEATER AND THERMISTOR DISASSEMBLY.
3 Separate the hose air from the sensor pressure. 4 Lay the front-side of washer on the floor.
And remove four screws.
5 Separate two dampers and the hose drain. 6 Lift up the cabinet as.
7 Separate the belt. 8 Remove two screws from the motor and remove the
screw from the drum using a box wrench.
