18
EXPLODE VIEW AND PARTS LIST
E01 CABINET 361081WA00 D-MU80 SGCC(GI) 0.7T COLD 1 COLD
361081WA01 D-MU80 SGCC 0.7T COLD+HOT COLD+HOT
E02 FRAME LOWER 36122UDR00 SGCC T=0.6 1
E03 BASE U L 3610394500 SGCC1.2T 1 LEFT
BASE U R 3610394600 SGCC1.2T 1 RIGHT
E04 LEG ADJUST AS 3617703800 FOOT(BUTYL)+SPECIAL NUT(SCP1) 4
+SPECIAL BOLT(10x1.25, 51MM)
3617703811 CHINA, FOOT+SPECIAL NUT(M10x1, 25P) ALTERNATE
E05 HARNESS AS 3612799E01 FULL OPTION 1
3612799E02 HOT/NON BUBBLE
3612799E03 NON HOT/BUBBLE
3612799E04 NON HOT/NON BUBBLE
3612799E05 NON EMI/FULL OPTION
3612799E06 NON EMI/HOT/NON BUBBLE
3612799E07 NON EMI/NON HOT/BUBBLE
3612799E08 NON EMI/NON HOT/NON BUBBLE
E06 UNIT DRAIN PUMP AS 36189L5K10 220-240V, 50Hz, 30W, AL, NO-HOLE 1
E07 SCREW TAPPING 7112401211 T1 TRS 4*12 MFZN 1
E08 HOSE DRAIN O AS 361326852T L=1800, STRAIGHT TYPE, CLAMP PI=27 1
E09 CLAMP HOSE 3611206410 NYLON, DA-16N, ID21.9 D-MU80 1
E10 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 1
E11 PLATE TOP AS 3614540710 D-NT1011 1
E12 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 2
E13 CORD POWER AS 3611339630 EU-2PIN H05VV-F 1.0SQ 250V 16A 1.4M 1
E14 SENSOR PRESSURE 3614825320 DL-DW12-H AIR INLET 270 HOOK TYPE 1
E17 SCREW TAPPING 7122401411 T2S TRS 4x14 MFZN 1
E15 FRAME UPPER 36122UDT00 SGCC 1.0T 1
E16 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 2 TOP FIX
(FRAME UPPER FIX) 3616029950 TTSS" HEX F/L 4*8 " 2 FRONT FIX
E18 FRAME TOP L 36122UDP00 SGCC T 1.4 1
FRAME TOP R 36122UDQ00 SGCC T 1.4 1
E19 EMI FILTER 3611910910 EMI FILTER DPC DFC-2712D-14A44GW 1
E20 SCREW TAPPING 7122401411 T2S TRS 4x14 MFZN 1
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
