Daewoo D35S-2 Service Manual

3 of 7
O-RING FACE SEAL FITTINGS
O-RING FACE SEAL FITTING
O-RING FACE SEAL NUT
IDAS001B
O-RING
O-RING GROOVE
STRAIGHT THREAD O-RING
PORT FITTING END
STRAIGHT THREAD O-RING
FITTING (FOR O-RING FACE
SEAL FITTING ONLY)
THREAD
SIZE
inch
5/16-24
3/8-24
7/16-20
1/2-20
9/16-18
3/4-16
7/8-14
1 1/16-12
1 3/16-12
1 5/16-12
1 5/8-12
1 7/8-12
2 1/2-12
(N
i
m)
5.0
± 1.5
12
± 2
20
± 4
30
± 5
40
± 5
100
± 15
135
± 15
200
± 25
250
± 25
300
± 40
300
± 40
300
± 40
300
± 40
(lb
i
ft)
45
±15 lb
i
in
110
±20 lb
i
in
15
± 3
22
± 4
30
± 4
75
± 10
100
± 10
150
± 20
185
± 20
225
± 30
225
± 30
225
± 30
225
± 30
STANDARD TORQUE
O-RING FACE SEAL FITTING NUT
THREAD
SIZE
inch
9/16-18
11/16-16
13/16-16
1-14
1 3/16-12
1 7/16-12
1 11/16-12
2-12
(N
i
m)
16
± 3
30
± 4
50
± 7
90
± 10
120
± 15
160
± 20
190
± 20
215
± 25
(lb
i
ft)
12
± 2
22
± 3
37
± 5
65
± 7
90
± 10
120
± 15
140
± 15
160
± 20
STANDARD TORQUE
