- 65 -
¥ Flywheel Housing
Tighten bolt to specified torque after liquid gusket is
applied on the gasket.
¥
Oil Pan
1) Install an oil fan after putting on oil fan gasket and
liquid gasket between cyliner block and oil fan.
¥
Oil Cooler
Assemble the oil cooler bolt in order(figure) after
putting liquid gasket and the oil cooler gasekt on the
block.
EJM2135S
EJM2172S
EJM2137S
EJM2138S
Oil Pump mounting Bolt Torque 5.3
L
1.0 kg¥ m
Torque 2.6
L
0.5 kg¥ m
Torque 2.6
L
0.5 kg¥ m
Bolt Torque 16.1
L
1 kg¥ m
Coupling
Bolt
