- 59 -
¥
Intake Manifold and Gasket
1) Assemble the intake manifold of which unchamfered
corner is toward up and rear of engine.
2) After assembling intake manifold, and assemble
the bolt to the specified torque in order. (see figure)
¥
Exhaust Manifold and Gasket
1) Assemble the exhaust manifold and gasket of
which "TOP" mark is shown.
2) After assembling the exhaust manifold, assemble
blots to the specified torque in order.(see figure)
EJM2114S
EJM2115S
TOP
EJM2116I
EJM2117S
Intake Manifold Bolt Torque 2. 6 L 0.5 kg¥ m
Exhaust Manifold Bolt Torque 2. 9 L 0.5 kg¥ m
Unchamfered corner
Rear
