Daewoo DLT-19W4 - Page 35

34
LOC PART CODE
PART NAME PART DESCRIPTION
C544 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C545 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C547 HCQK180JBA C CHIP CERA 50V CH 18PF J 1608
C548 HCQK180JBA C CHIP CERA 50V CH 18PF J 1608
C551 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C557 HCEJK109MC C CHIP ELECTRO MV 50V 1MF 4.0DX5.3H
C558 HCEJK109MC C CHIP ELECTRO MV 50V 1MF 4.0DX5.3H
C561 HCQK221JBA C CHIP CERA 50V CH 220PF J 1608
C591 HCEJF100MC C CHIP ELECTRO 16V 10MF MV 4052
C621 HCBF224KBA C CHIP CERA 16V X7R 0.22MF K 1608
C622 HCBK153KBA C CHIP CERA 50V X7R 0.015MF K 1608
C625 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C626 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C628 HCBK153KBA C CHIP CERA 50V X7R 0.015MF K 1608
C631 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C640 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C641 HCBF224KBA C CHIP CERA 16V X7R 0.22MF K 1608
C644 HCEEF101MC C CHIP ELECTRO MV 16V 100MF 6.3DX5.7H
C645 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C646 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C647 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
C648 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
C649 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C650 HCBF224KBA C CHIP CERA 16V X7R 0.22MF K 1608
C651 HCBF224KBA C CHIP CERA 16V X7R 0.22MF K 1608
C656 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C668 HCEJF470MC C CHIP ELECTRO 16V 47MF CS 6352
C671 HCELH100MC C CHIP ELECTRO 25V 10MF CM 4052
C904 HCEEF101MC C CHIP ELECTRO MV 16V 100MF 6.3DX5.7H
C911 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C912 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C913 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C914 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C923 HCELF471ME C CHIP ELECTRO 16V 470MF CM 8010
C928 HCEEF101MC C CHIP ELECTRO MV 16V 100MF 6.3DX5.7H
C934 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C938 HCEEF101MC C CHIP ELECTRO MV 16V 100MF 6.3DX5.7H
C940 HCEEF101MC C CHIP ELECTRO MV 16V 100MF 6.3DX5.7H
C942 HCEJF470MC C CHIP ELECTRO 16V 47MF CS 6352
C944 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C963 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C964 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C965 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C966 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C967 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C984 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CA33 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CA34 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CA35 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CA36 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CA44 HCELK479MC C CHIP ELECTRO 50V 4.7MF CM 4052
CA47 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
LOC PART CODE
PART NAME PART DESCRIPTION
RD26 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RD27 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RD28 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RD29 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RD30 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RD31 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RD32 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RD33 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RD34 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
RD35 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
RD36 HRFT470JBA R CHIP 1/10 47 OHM J 1608
RD37 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RD38 HRFT470JBA R CHIP 1/10 47 OHM J 1608
RD40 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RD41 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RD50 HRFT151JBA R CHIP 1/10 150 OHM J 1608
RD53 HRFT470JBA R CHIP 1/10 47 OHM J 1608
RD56 HRFT473JBA R CHIP 1/10 47K OHM J 1608
RD76 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RD91 HRFT000JBA R CHIP 1/10 0 OHM J 1608
RD93 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RD96 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RD97 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RD99 HRFT103JBA R CHIP 1/10 10K OHM J 1608
RQ15 HRFT472JBA R CHIP 1/10 4.7K OHM J 1608
ZZ200 PTMPJ1G105 PCB CHIP MOUNT
A AS
DLT-19W4LMBSCF
100 2193220009 SOLDER CREAM PJ790-G0061
A001 4859818992 PCB MAIN SL-150T 234X189 K4V (WIDE)
C402 HCEJF100MC C CHIP ELECTRO 16V 10MF MV 4052
C403 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C404 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C420 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C501 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C502 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C503 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C504 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C505 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C506 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C508 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C509 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C510 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C511 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C512 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C514 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C515 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C516 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C517 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C518 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C541 HCFK103ZBA C CHIP CERA 50V Y5V 0.01MF Z 1608
C542 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
C543 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
Service part list (DLT-19W4)
