Daewoo DLT-19W4 - Page 36

35
LOC PART CODE
PART NAME PART DESCRIPTION
CD92 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CD93 HCEJF100MC C CHIP ELECTRO 16V 10MF MV 4052
CD94 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CD95 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CP01 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CP03 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CP05 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CP07 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CP1 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CP18 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CP22 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CP25 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CP29 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CP35 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CP40 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CP48 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CP51 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CP65 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
D401 DBAV70---B DIODE CHIP BAV70
D911 DM2FM3---C
DIODE CHIP SCHOTTKY M2FM3 M2F TYPE
D912 DM2FM3---C
DIODE CHIP SCHOTTKY M2FM3 M2F TYPE
D913 DM2FM3---C
DIODE CHIP SCHOTTKY M2FM3 M2F TYPE
D923 DBAV70---B DIODE CHIP BAV70
DA03 DBAV70---B DIODE CHIP BAV70
DA71 DBAV70---B DIODE CHIP BAV70
I403 124C04MN6D IC CHIP EEPROM M24C04-WMN6T
I501 1FL130602Q
IC CHIP VIDEO DE-
CODER
FLI30602H
I505 125VF016-Q
IC CHIP FLASH MEMORY SST25VF016
I601 1TDA8933-Q IC CHIP AUDIO AMP TDA8933
I902 1G9173363C IC CHIP REGULATOR G9117-33T63U 3.3V
SOT-223
I907 1MP1583--D IC CHIP CONVERTER MP1583DN
I911 1AZ117H25C IC CHIP REGULATOR AZ1117H-2.5TREI 2.5V
SOT-223
I912 1MP1583--D IC CHIP CONVERTER MP1583DN
I913 1MP1583--D IC CHIP CONVERTER MP1583DN
I914 1LM317BD2E IC CHIP REGULATOR
LM317BD2T ADJ 1.2V 37V
1.5A D2PAK
I915 TFDS4953-C FET CHIP FDS4953 SO-8 -30V -5A
REEL
I916 1G95110T-C IC CHIP REGULATOR G951-10T65U SOT-223
I921 1LM317BD2E IC CHIP REGULATOR
LM317BD2T ADJ 1.2V
37V 1.5A D2PAK
IA05 1M74HC14TC IC CHIP LOGIC M74HC14TTR
ICD13 1STV0362-Q IC CHIP CHANNEL
DECODER
STV0362
ID01 1C1GU04GWD IC CHIP INVERTER 74AHC1GU04GW
ID02 1ST5105--Q
IC CHIP MEDIA PROCES-
SOR
ST5105
ID03 11216AJTAQ IC CHIP DDR SDRAM EDD1216AJTA-5B-E
ID05 1HC1G32GWD IC CHIP OR GATE 74AHC1G32GW
LOC PART CODE
PART NAME PART DESCRIPTION
CA48 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CA49 HCELK479MC C CHIP ELECTRO 50V 4.7MF CM 4052
CA61 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CA63 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CA66 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CA67 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CA70 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CA71 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CA72 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CA81 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CA83 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CA87 HCEJF100MC C CHIP ELECTRO 16V 10MF MV 4052
CA88 HCEJF100MC C CHIP ELECTRO 16V 10MF MV 4052
CD01 HCEJF470MC C CHIP ELECTRO 16V 47MF CS 6352
CD04 HCEJK109MC C CHIP ELECTRO MV 50V 1MF 4.0DX5.3H
CD05 HCEJK109MC C CHIP ELECTRO MV 50V 1MF 4.0DX5.3H
CD06 HCEJF100MC C CHIP ELECTRO 16V 10MF MV 4052
CD08 HCEJF100MC C CHIP ELECTRO 16V 10MF MV 4052
CD10 HCELK479MC C CHIP ELECTRO 50V 4.7MF CM 4052
CD103 HCQK270JBA C CHIP CERA 50V CH 27PF J 1608
CD106 HCQK270JBA C CHIP CERA 50V CH 27PF J 1608
CD120 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CD121 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CD122 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CD123 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CD124 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CD13 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
CD130 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CD14 HCQK220JBA C CHIP CERA 50V CH 22PF J 1608
CD20 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CD25 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CD36 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CD38 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CD39 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CD48 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CD50 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CD52 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CD61 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052
CD62 HCEJK109MC C CHIP ELECTRO MV 50V 1MF 4.0DX5.3H
CD65 HCQK270JBA C CHIP CERA 50V CH 27PF J 1608
CD68 HCQK270JBA C CHIP CERA 50V CH 27PF J 1608
CD72 HCEJK109MC C CHIP ELECTRO MV 50V 1MF 4.0DX5.3H
CD74 HCELK479MC C CHIP ELECTRO 50V 4.7MF CM 4052
CD87 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CD88 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
Service part list (DLT-19W4)
