Daewoo DLT-19W4 - Page 37

36
LOC PART CODE
PART NAME PART DESCRIPTION
ID07 174LVC162D IC CHIP BUFFER 74LVC16244
ID08 174L16244D IC CHIP BUFFER 74LVTH16244
ID09 1C1GU04GWD IC CHIP INVERTER 74AHC1GU04GW
ID10 1HEF4053BD IC CHIP LOGIC HEF4053B
ID11 1HC1G32GWD IC CHIP OR GATE 74AHC1G32GW
ID12 1HC1G32GWD IC CHIP OR GATE 74AHC1G32GW
ID13 1C245APW-D IC CHIP TRANSCEIVER 74LVC245APW
ID14 174LVC162D IC CHIP BUFFER 74LVC16244
ID17 174HC126PD IC CHIP BUFFER 74HC126PW-T
ID18 1160ET70NQ IC CHIP FLASH MEMORY M29W160ET70N6T
ID511 174HC126PD IC CHIP BUFFER 74HC126PW-T
JP401 4859201660 CONN HDMI WF050-21UBR STR.
SHEEL REEL TYPE
JP502 4859293820 CONN WAFER GT121-31P-TD-A
31P ST
L421 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L431 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L432 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L523 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L524 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L601 HLC479K03C L CHIP COIL 4.7UH K NLC5650T
L610 HLC470KECE L CHIP COIL 47UH K 1280
L620 HLC470KECE L CHIP COIL 47UH K 1280
L626 HLC479K03C L CHIP COIL 4.7UH K NLC5650T
L901 HLC150KECE L CHIP COIL 15UH K 1280
L902 HLC150KECE L CHIP COIL 15UH K 1280
L903 HLC150KECE L CHIP COIL 15UH K 1280
L912 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L913 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L915 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L916 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L917 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L918 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L922 HLC479J00A L CHIP COIL 4.7UH MLF2012
L923 HLC479J00A L CHIP COIL 4.7UH MLF2012
L932 HLC479K03C L CHIP COIL 4.7UH K NLC5650T
L933 HLC479K03C L CHIP COIL 4.7UH K NLC5650T
L951 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L952 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L953 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L954 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L955 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L956 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L957 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L958 HLC479K03C L CHIP COIL 4.7UH K NLC5650T
LOC PART CODE
PART NAME PART DESCRIPTION
L961 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L962 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L963 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L964 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L965 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L966 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L967 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L971 HLC479J00A L CHIP COIL 4.7UH MLF2012
L973 HLC479J00A L CHIP COIL 4.7UH MLF2012
L974 HLC479K03C L CHIP COIL 4.7UH K NLC5650T
L975 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L976 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L977 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L978 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L979 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L980 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L987 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
L988 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LA35 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LA61 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
LD01 HLC189K00A L CHIP COIL 1.8UH K MLF 2012
LD02 HLC479K03C L CHIP COIL 4.7UH K NLC5650T
LD03 HLC189K00A L CHIP COIL 1.8UH K MLF 2012
LD04 HLC189K00A L CHIP COIL 1.8UH K MLF 2012
LD05 HLC189K00A L CHIP COIL 1.8UH K MLF 2012
LD25 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S
Q503 T2SC2412KB TR CHIP 2SC2412KB
Q504 T2SA1037KB TR CHIP 2SA1037KB
Q622 T2SC2412KB TR CHIP 2SC2412KB
Q902 T2SC2412KB TR CHIP 2SC2412KB
Q905 T2SC2412KB TR CHIP 2SC2412KB
QD06 T2SC2412KB TR CHIP 2SC2412KB
QD07 T2SC2412KB TR CHIP 2SC2412KB
QD08 T2SC2412KB TR CHIP 2SC2412KB
QD10 T2SC2412KB TR CHIP 2SC2412KB
QD11 T2SC2412KB TR CHIP 2SC2412KB
R401 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R402 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R406 HRFT473JBA R CHIP 1/10 47K OHM J 1608
R407 HRFT473JBA R CHIP 1/10 47K OHM J 1608
R409 HRFT101JBA R CHIP 1/10 100 OHM J 1608
R410 HRFT000JBA R CHIP 1/10 0 OHM J 1608
R411 HRFT000JBA R CHIP 1/10 0 OHM J 1608
R419 HRFT104JBA R CHIP 1/10 100K OHM J
1608
R451 HRTS8E100J R CHIP ARRAY 1/16 8P 10 OHM 3216
Service part list (DLT-19W4)
