Daewoo DLT-26C2 - Other Functions

51
PR/PAGE
SELECT
PR/PAGE
PR/PAGE
SELECT
PR/PAGE
PR/PAGE
SELECT
PR/PAGE
ON
OFF
LANGUAGE
TIMER
CHILD LOCK OFF
MGDI DEMO
OSD HALFTONE 0
POSITION ACCESS EXIT
FUNCTION
LANGUAGE
TIMER
CHILD LOCK OFF
MGDI DEMO
OSD HALFTONE 0
POSITION ACCESS EXIT
FUNCTION
LANGUAGE
TIMER
CHILD LOCK OFF
MGDI DEMO
OSD HALFTONE 0
POSITION ACCESS EXIT
FUNCTION
EXITMGDI
Other Functions
1. Setup of Child Lock
• Move to Child Lock in the Function menu.
• Select Child Lock to “On” using the “” button
Note :
• This prevents the use of the TV set without the remote con-
trol.
• If TV set is set up Child Lock, LED will cycle through red/off for
the ST-BY mode.
• If the Child Lock is “On”, then the set can only be switched back
on using the remote control.
2. Setup of MGDI Demo
• Move to MGDI Demo in the Function menu.
• Press the “” button, and then screen changes as below.
• Press the “MENU” button, and then return to origin screen.
Note :
• One can move on MGDI DEMO menu directly using „MGDI” but-
ton on the remote control.
3. OSD Halftone
• Move to OSD Halftone in the Function menu.
• Press the “” button, and then the OSD’s transparency chang-
es from 0 to 100 by 25 (5 steps).
• Press the „MENU” button, and then return to origin screen.
