-11-
5. Service Mode
To enter SERVICE MODE,
A. Press “
VOL” -> “MUTE ” -> “RECALL” -> “MUTE” button of remote controller
(R-55E05)
or
B. Press “S9” button of SERVICE REMOTE CONTROLLER.
[Note] In the first line, there is the model name and the version of the upgraded program
on the PDP set.
5-1. Default Value of Pw338B_1 and Pw338B_2
RGB offset values will be set by executing ‘RGB Auto Cal’ in service mode.
YPbPr offset values will be set by executing ‘YPbPr Auto Cal’ in service mode.
1) Pw338B_1
Sub Bias : For BRIGHTNESS adjustment (All inputs)
Sub Gain : For CONTRAST adjustment (All inputs)
Bias R : For R BRIGHTNESS adjustment (All inputs)
Bias G : For G BRIGHTNESS adjustment (All inputs)
Bias B : For B BRIGHTNESS adjustment (All inputs)
Gain R : For R CONTRAST adjustment (All inputs)
Gain G : For G CONTRAST adjustment (All inputs)
Gain B : For B CONTRAST adjustment (All inputs)
2) Pw338B_2
Sub Bias : For HDMI BRIGHTNESS adjustment
Sub Gain : For HDMI CONTRAST adjustment
5-2. FrontEnd_1
Function R Offset G Offset B Offset R Gain G Gain B Gain
Default Value 512 512 512 512 512 512
Function Y Offset Pb Offset Pr Offset Y Gain Pb Gain Pr Gain
Default Value 512 512 512 512 512 512
Sub Bias Sub Gain Bias R Bias G Bias B Gain R Gain G Gain B
Pw338B_1 32 72 32 30 41 28 32 45
Pw338B_2 32 64
